SKU: CJ1W-PD022
Omron CJ1W-PD022 DC Power Supply Unit 24VDC for CJ Series
Omron CJ1W-PD022 is a DC power supply unit for CJ series PLCs, converting 24VDC to 5VDC for backplane power.
USD 38.00 per unit, volume discounts available
- In stock, ships in 24h
- 100% genuine Omron
- 1-year manufacturer warranty
- Worldwide delivery
Key Features
- CJ-series dedicated PLC power supply unit
- Wide 100-240VAC input compatibility for global panel standards
- Supports stable operation of CJ CPU and expansion modules
- Essential component for reliable rack-level system power
- Suitable for new installations and maintenance replacement
- Helps preserve continuity in long-life CJ platform deployments
Core PLC Rack Power for Stable CJ System Operation
The CJ1W-PD022 supplies dependable operating power to CJ PLC racks and connected modules, supporting continuous control performance in demanding industrial environments. It is commonly used in both new panel builds and maintenance replacement for installed CJ systems. A stable PSU foundation improves controller reliability, communication consistency, and long-term lifecycle serviceability.
Typical Applications
- Powering CJ PLC racks in machine control panels
- Replacing failed PSU units in maintenance interventions
- Supporting stable operation of CJ CPU and I/O modules
- Standardizing CJ power modules across plant assets
- Extending lifecycle of existing CJ automation lines
- Ensuring consistent rack power in retrofit panel upgrades
Buying Checklist
- Proven compatibility for CJ platform continuity
- Wide AC input supports flexible deployment environments
- Critical for maintaining reliable PLC system uptime
- Practical spare-part for installed-base maintenance
- Supports low-risk lifecycle management of legacy controls
Technical Specifications
| Model | CJ1W-PD022 |
|---|---|
| Series | CJ1W |
| Type | DC Power Supply Unit |
| Input Voltage | DC24V (20.4-28.8V) |
| Output Voltage | 5VDC (backplane) |
| Output Current | 5A |
| Output Power | 25W |
| Efficiency | 85% typical |
| Protection | Overcurrent, overvoltage, reverse polarity |
| Connection | Terminal block |
| Current Consumption | 6A at 24VDC |
| Operating Temperature | 0 to +55°C |
| Mounting | CJ series backplane |
Frequently Asked Questions
When should I use DC power supply vs AC?
DC (PD022): when your panel already has 24VDC distribution, for battery backup systems, mobile equipment. AC (PA202): direct connection to mains power. Choose based on available power source.
What's the advantage of DC input?
DC input: no inrush current, higher efficiency (85% vs 75%), reverse polarity protection, compatible with battery/UPS backup. Preferred for critical applications.
How many I/O units can PD022 support?
Same as PA202: approximately 20-30 I/O units (5A at 5VDC). Calculate total 5VDC consumption of all units before sizing.
Do I need fuse on 24VDC input?
Yes, external fuse recommended: 10A slow-blow for PD022. Protects wiring and supply from short circuits. Install close to power supply input.
Related Products
Customers who viewed CJ1W-PD022 often pair it with these.
Need CJ1W-PD022 pricing or lead time?
Email sales@hyx-automation.com or send your inquiry via the form. We respond same business day.
Send Inquiry
