SKU: CP1W-40EDT1
Omron CP1W-40EDT1 Expansion Unit 24 Input 16 PNP Output
Omron CP1W-40EDT1 is a 40-point expansion unit for CP1 series PLCs with 24 DC inputs and 16 PNP transistor outputs.
USD 88.00 per unit, volume discounts available
- In stock, ships in 24h
- 100% genuine Omron
- 1-year manufacturer warranty
- Worldwide delivery
Key Features
- 40-point digital I/O expansion for CP1 architectures
- Supports significant capacity growth in compact PLC systems
- Suitable for machine feature expansion and retrofit upgrades
- Helps preserve existing controller logic investment
- Improves scalability of OEM platform designs
- Practical module for high-I/O panel standardization
High-Capacity CP1 I/O Expansion for Scalable Machine Platforms
The CP1W-40EDT1 adds substantial digital I/O capacity to CP1 systems where machine functionality is growing beyond base controller limits. It enables OEMs and integrators to expand control features without full platform migration. This unit supports practical retrofit and new-build expansion strategies with consistent addressing and maintainable wiring design.
Typical Applications
- Adding I/O points for new machine options
- Expanding actuator and sensor channels in CP1 systems
- Upgrading legacy panels to support more automation steps
- Standardizing 40-point expansion blocks in OEM builds
- Reducing immediate need for controller platform migration
- Improving capacity planning in phased control projects
Buying Checklist
- Large I/O increase within existing CP1 architecture
- Helps avoid costly full controller replatforming
- Supports repeatable OEM panel expansion standards
- Strong maintenance fit for installed CP1 fleets
- Practical choice for phased machine capability growth
Technical Specifications
| Model | CP1W-40EDT1 |
|---|---|
| Series | CP1W |
| Type | Expansion I/O Unit |
| Total Points | 40 points (24 input, 16 output) |
| Input Points | 24 DC inputs |
| Output Points | 16 PNP transistor outputs |
| Output Current | 0.3A per point |
| Load Voltage | DC12-24V |
| Connection | Removable terminal block |
| Current Consumption | 200mA at 5VDC |
| Compatible CPUs | CP1E, CP1L, CP1H |
| Operating Temperature | 0 to +55°C |
Frequently Asked Questions
What's the difference between 40EDR and 40EDT1?
40EDR: relay output (5A, AC/DC). 40EDT1: PNP transistor output (0.3A, DC only). Choose 40EDR for AC/high current, 40EDT1 for DC/high-speed.
What's the maximum total current?
0.3A per point, 1.2A per common (8 points), 4.8A total unit maximum. Plan load distribution to stay within ratings.
Can I use this for solenoid valve control?
Yes, common application. 0.3A per point suits most 24VDC solenoid valves (typically 0.1-0.2A each). Add flyback diode for inductive load protection.
How do I wire PNP output?
Load + to 24V+, load - to output terminal. Output switches 24V+ to load when ON. Common terminal connects to 24V+.
