SKU: E2E-X3D1-U
Omron E2E-X3D1-U Inductive Proximity Sensor M12 3mm AC/DC Free Voltage
Omron E2E-X3D1-U is an M12 inductive proximity sensor with 3mm sensing distance, AC/DC free voltage output for versatile power supply options.
USD 30.00 per unit, volume discounts available
- In stock, ships in 24h
- 100% genuine Omron
- 1-year manufacturer warranty
- Worldwide delivery
Key Features
- E2E-series inductive proximity sensing platform
- Non-contact detection of metallic targets
- Suitable for high-cycle machine position/presence tasks
- Practical fit for compact industrial installations
- Integrates with PLC discrete input circuits
- Supports low-maintenance sensing strategy
Compact Inductive Sensing for Reliable Metal Detection Tasks
E2E-X3D1-U belongs to Omron E2E inductive sensor family and is used where machines require durable non-contact detection of metallic parts or reference positions. Inductive sensors are commonly selected for indexing systems, actuator end-position checks, and transfer-mechanism presence detection because they avoid mechanical wear and provide stable switching in high-cycle use. This model is often used in compact automation modules where mounting space and service simplicity are important. Engineering teams should verify target material response, sensing margin, installation style, and control input compatibility. Commissioning should include repeatability checks under vibration and thermal variations relevant to production. E2E-X3D1-U is generally selected when builders need robust metal detection with low maintenance overhead.
Typical Applications
- Metal part presence sensing in assembly fixtures
- End-position detection on pneumatic/electric actuators
- Index mechanism reference detection
- Conveyor transfer point metal-target verification
- Retrofit replacement of mechanical limit switches
- Machine sequence interlock sensing for cycle control
Buying Checklist
- Confirm target material and sensing margin requirements.
- Check output compatibility with controller input channels.
- Validate mount style and installation clearance.
- Protect cables from repetitive motion and abrasion.
- Include periodic mechanical inspection in maintenance plan.
Technical Specifications
| Model | E2E-X3D1-U |
|---|---|
| Series | E2E |
| Size | M12 |
| Sensing Distance | 3mm |
| Output Type | AC/DC (relay) |
| Supply Voltage | AC/DC 24-240V (free voltage) |
| Load Current | 200mA |
| Response Time | 20ms |
| Cable Length | 2m |
| Protection | IP67 |
| Operating Temperature | -25 to +70°C |
Frequently Asked Questions
What's the advantage of AC/DC free voltage?
Works with both AC and DC power supplies (24-240V). One sensor model for global applications. Simplifies inventory and replacement.
What's the output type?
AC/DC output (internal relay). Can switch both AC and DC loads. Suitable for direct control of contactors, relays, and indicators.
Why is response time slower than DC sensors?
AC/DC sensors use internal relay output (20ms) vs transistor output (1ms). Relay provides isolation and AC/DC switching but slower response. Choose based on application requirements.
Can I use this for direct motor control?
No, 200mA rating is too low for motors. Use sensor to control relay/contactor coil, which switches motor power.
