Omron E5CC-QX2ASM-800 Digital Temperature Controller 48x96mm Universal Input
Omron E5CC-QX2ASM-800 is a 48x96mm digital temperature controller with universal input (thermocouple/Pt100/analog), relay/SSR/current output for precise industrial temperature control.
USD 35.00 per unit, volume discounts available
- In stock, ships in 24h
- 100% genuine Omron
- 1-year manufacturer warranty
- Worldwide delivery
Key Features
- 48x96mm compact size
- Universal input (TC/Pt100/analog)
- Selectable output (relay/SSR/current)
- PID control with auto-tuning
- Large white PV display
- Heater burnout detection
- Event input function
- IP66 front panel protection
Omron E5CC-QX2ASM-800 Digital Temperature Controller
The Omron E5CC-QX2ASM-800 is a 48x96mm digital temperature controller from the E5_C series, featuring universal input capability for thermocouple, Pt100, or analog signals. This controller provides flexible output options including relay, SSR drive, or current output for controlling heaters, coolers, or other temperature control devices. The large white PV display provides excellent visibility, while the intuitive front panel keys enable easy setup and operation. Features include ON/OFF or PID control with auto-tuning, heater burnout detection, event inputs, and communication options. Ideal for packaging machinery, plastic molding, food processing, and industrial heating applications.
Typical Applications
- Plastic injection molding
- Packaging machinery heating
- Food processing equipment
- Industrial ovens and furnaces
- HVAC systems
- Laboratory equipment
Buying Checklist
- Universal input flexibility
- Industry-standard 48x96mm size
- Easy setup and operation
- Reliable Omron quality
Technical Specifications
| Model | E5CC-QX2ASM-800 |
|---|---|
| Series | E5CC |
| Type | Digital Temperature Controller |
| Size | 48 x 96mm (1/16 DIN) |
| Input Types | Universal: TC (K,J,T,E,L,U,N,R,S,B,W), Pt100, Analog (4-20mA, 0-10V) |
| Control Output 1 | Relay (SPST-NO) or SSR drive or Current (4-20mA) |
| Control Output 2 | Auxiliary relay or current output |
| Control Method | ON/OFF or PID with auto-tuning |
| Control Period | 0.5-120 seconds (adjustable) |
| Sampling Period | 250ms |
| Accuracy | ±0.3% of display value ±1 digit |
| Display | White PV (11-segment, 15.2mm), Orange SV |
| Supply Voltage | AC100-240V 50/60Hz |
| Power Consumption | 5.2VA max |
| Alarm Outputs | 2 alarm outputs (relay) |
| Heater Burnout Detection | Yes (with optional CT) |
| Communication | Optional (RS-485, Ethernet) |
| Front Panel Protection | IP66 |
| Operating Temperature | -10 to +55°C |
| Mounting | Panel mount (45-55mm thickness) |
Frequently Asked Questions
What's the difference between E5CC, E5EC, and E5AC series?
Size: E5EC=48x48mm (1/16 DIN), E5CC=48x96mm (1/8 DIN), E5AC=96x96mm (1/4 DIN). Larger sizes offer dual displays, more outputs, and better visibility. Choose based on panel space and feature requirements.
How do I tune the PID parameters for my heating system?
Use auto-tuning (AT): press and hold AT key for 3 seconds. Controller applies step change, measures response, calculates optimal P, I, D values. Takes 2-3 heating cycles. For fine-tuning, adjust P (proportional band), I (integral time), D (derivative time) manually based on overshoot and oscillation.
What's the difference between relay, SSR, and current output?
Relay: mechanical contact, suitable for contactors/valves, limited life (100K cycles). SSR drive: voltage pulse for solid state relays, no wear, high-cycle. Current (4-20mA): for proportional control of power controllers, precise temperature control. Choose based on final control element and control precision needs.
How do I detect heater burnout?
Install current transformer (CT) around heater supply wire. Controller monitors heater current. If current drops below set threshold while output is ON, heater burnout alarm triggers. Essential for preventing product quality issues from failed heaters.
Can I connect this controller to my PLC or SCADA system?
Yes, add optional communication card: RS-485 (Modbus-RTU) for PLC connection, or Ethernet for SCADA/IIoT. Enables remote setpoint changes, temperature monitoring, alarm notification, and data logging.
