SKU: NX102-1000
Omron NX102-1000 Machine Automation Controller CPU Unit
Omron NX102-1000 is an NX102 series machine automation controller combining PLC, motion control, and robotics in one platform.
USD 835.00 per unit, volume discounts available
- In stock, ships in 24h
- 100% genuine Omron
- 1-year manufacturer warranty
- Worldwide delivery
Key Features
- Program Capacity: 100K steps
- Motion Axes: 16 axes (via EtherCAT)
- EtherCAT Ports: 2 ports (100 Mbps)
- Ethernet Ports: 2 ports (10/100 Mbps)
- USB Ports: 2 ports
- Max I/O Points: 4096 points
Scalable PLC Control Foundation for OEM and Retrofit Projects
The NX102-1000 fits industrial control projects that require dependable logic execution, maintainable programming workflows, and architecture growth over the equipment lifecycle. It supports standardized automation design across machine families while preserving serviceability in production environments.
Deterministic Logic and Sequence Control
This controller class supports predictable scan-driven execution for interlocks, sequencing, alarms, and coordinated device handling. Deterministic behavior is essential for consistent machine output and repeatable cycle performance.
Platform Reuse Across Equipment Variants
Standardizing on a proven PLC/controller family enables software reuse, reduced engineering lead time, and easier support across multiple machine models or production lines.
Lifecycle Service and Maintainability
A maintainable control architecture with documented I/O mapping, diagnostics, and modular expansion strategy reduces troubleshooting time and improves long-term ownership value.
Typical Applications
- Executes deterministic control logic
- Coordinates multi-device machine behavior
- Supports reusable software structures
- Improves fault diagnostics and recovery time
- Enables modular feature growth over time
- Standardizes control strategy across equipment
Buying Checklist
- Strong fit for scalable machine control
- Maintains deterministic automation behavior
- Supports long-term maintainability
- Good platform standardization candidate
- Reliable industrial controller ecosystem
Technical Specifications
| Model | NX102-1000 |
|---|---|
| Series | NX102 |
| Type | Machine Automation Controller |
| Program Capacity | 100K steps |
| Motion Axes | 16 axes (via EtherCAT) |
| EtherCAT Ports | 2 ports (100 Mbps) |
| Ethernet Ports | 2 ports (10/100 Mbps) |
| USB Ports | 2 ports |
| Max I/O Points | 4096 points |
| Cycle Time | 1ms (typical) |
| Motion Cycle | 0.5ms |
| Supply Voltage | DC24V |
| Operating Temperature | 0 to +55°C |
| Software | Sysmac Studio |
| Mounting | DIN rail |
Frequently Asked Questions
What's the advantage of NX102 series?
High-performance machine controller: PLC, motion, robotics in one unit. More axes than NJ501, faster cycle time. Ideal for complex automation systems.
How many axes can this controller control?
16 motion axes via EtherCAT. Connect R88D servo drives or third-party EtherCAT servo drives. Suitable for multi-axis robotics and complex machines.
Can this controller handle robotics?
Yes, NX102 supports robotics kinematics, coordinate transformations, path planning. Suitable for SCARA, Cartesian, and simple articulated robots.
What programming software is required?
Sysmac Studio: single environment for PLC programming, motion configuration, robotics, HMI design. Same software for all NJ/NX series.
