SKU: R88M-1M40030T-S2
Omron R88M-1M40030T-S2 AC Servo Motor 400W 3000rpm 1S Series
Omron R88M-1M40030T-S2 is a 1S series AC servo motor with 400W power, 3000rpm rated speed, smooth shaft for general automation in packaging and assembly machinery.
USD 170.00 per unit, volume discounts available
- In stock, ships in 24h
- 100% genuine Omron
- 1-year manufacturer warranty
- Worldwide delivery
Key Features
- 400W servo motor class for precise medium-duty axes
- High-speed class up to 6000rpm for dynamic motion tasks
- Supports accurate positioning and repeatable cycle behavior
- Suitable for packaging, robotics, and assembly applications
- Integrates with closed-loop servo drive ecosystems
- Reliable performance for long-duty production environments
High-Speed Precision Servo Motor for Demanding Axis Performance
The R88M-1M40030T-S2 supports machine axes that require fast response, accurate positioning, and stable repeatability across high-cycle operation. Its 400W power class and high-speed capability fit packaging, assembly, and robotic handling tasks where cycle time directly impacts throughput. This motor is a strong choice for OEMs standardizing precise medium-duty motion channels.
Typical Applications
- Driving high-speed indexing mechanisms
- Controlling robotic transfer axes
- Powering precision feed and positioning systems
- Upgrading slower legacy servo axes
- Implementing repeatable motion in packaging lines
- Standardizing 400W motion channels in OEM designs
Buying Checklist
- High-speed capability improves cycle-time potential
- 400W class balances performance and integration footprint
- Strong fit for precision-driven automation tasks
- Supports consistent quality in motion-sensitive processes
- Practical long-term component for scalable servo platforms
Technical Specifications
| Model | R88M-1M40030T-S2 |
|---|---|
| Series | 1S Series |
| Rated Output | 400W |
| Rated Speed | 3000rpm |
| Rated Voltage | 200V AC |
| Rated Torque | 1.27 Nm |
| Peak Torque | 3.82 Nm |
| Shaft Type | Smooth shaft |
| Brake | Without brake |
| Encoder | Incremental 17-bit |
| Frame Size | 60mm |
| Mass | Approx. 1.1kg |
| Protection | IP65 |
Frequently Asked Questions
What is the power rating?
400W at 3000rpm for medium-load automation applications.
Does this have a brake?
No, smooth shaft without brake. For brake model, select R88M-1M40030T-BS2.
What drives work with this motor?
R88D-1SN04H-ECT or higher rated 1S series EtherCAT drives.
What is the shaft diameter?
14mm smooth shaft for coupling applications.
