SKU: WL-3A100(WLCAL4-2 LEVER)
Omron WL-3A100 Limit Switch with WLCAL4-2 Lever
Omron WL-3A100 is a limit switch with WLCAL4-2 lever actuator for industrial position sensing and travel limit applications.
USD 8.50 per unit, volume discounts available
- In stock, ships in 24h
- 100% genuine Omron
- 1-year manufacturer warranty
- Worldwide delivery
Key Features
- Contact Configuration: SPDT (1 Form C)
- Contact Rating: 10A at 250VAC
- Actuator Type: WLCAL4-2 lever
- Operating Force: Variable by lever
- Mechanical Life: 5 million operations
- Electrical Life: 50,000 operations
Reliable Detection Layer for Sequence Accuracy and Process Stability
The WL-3A100(WLCAL4-2 LEVER) is used to deliver repeatable machine-state detection for sequencing, interlocks, and process confirmation. Whether in packaging, handling, or assembly systems, this sensing class helps reduce false triggers and improves control confidence under continuous operation.
Repeatable State Detection
Accurate detection at the right process moment improves sequence integrity and reduces quality escapes caused by timing uncertainty or missed events.
Fit for Demanding Machine Environments
Industrial sensing components are selected for stability under vibration, contamination, and repetitive duty where consumer-grade devices are not suitable.
Faster Commissioning and Replacement
Standardized sensor families simplify spare strategy, reduce replacement errors, and support quicker return to production after maintenance events.
Typical Applications
- Provides stable detection signals to PLC logic
- Improves sequence timing accuracy
- Reduces dependence on mechanical contact methods
- Supports high-cycle production operation
- Enables better fault isolation at machine stations
- Simplifies maintenance through standard sensor families
Buying Checklist
- Repeatable industrial detection behavior
- Designed for continuous machine duty
- Improves process timing confidence
- Serviceable and standardizable selection
- Reliable fit for automation sensing layers
Technical Specifications
| Model | WL-3A100(WLCAL4-2 LEVER) |
|---|---|
| Series | WL |
| Contact Configuration | SPDT (1 Form C) |
| Contact Rating | 10A at 250VAC |
| Actuator Type | WLCAL4-2 lever |
| Operating Force | Variable by lever |
| Mechanical Life | 5 million operations |
| Electrical Life | 50,000 operations |
| Protection | IP64 |
| Operating Temperature | -25 to +70°C |
| Terminal Type | Screw terminals |
| Conduit Size | G1/2 or 1/2-14NPT |
Frequently Asked Questions
What's the WLCAL4-2 lever?
Adjustable lever actuator with roller. Lever length adjustable for different operating positions. Roller reduces friction and wear.
Can I change the lever?
Yes, WL series supports various lever actuators (sold separately). Choose lever based on operating position and force requirements.
What's the protection rating?
IP64: dust-tight, splash-proof. Suitable for indoor industrial environments. For outdoor or washdown, use higher IP rating switches.
Can this switch be used for safety interlocks?
No, WL series is not certified for safety applications. For safety interlocks, use D4 series safety limit switches with direct opening action.
