SKU: 3G3MX2-A4110-V2
Omron 3G3MX2-A4110-V2 MX2 Inverter Drive 11kW 400V
Omron 3G3MX2-A4110-V2 is an 11kW MX2 series VFD with three-phase 400V input for high-power motor speed control in industrial applications.
USD 378.00 per unit, volume discounts available
- In stock, ships in 24h
- 100% genuine Omron
- 1-year manufacturer warranty
- Worldwide delivery
Key Features
- 11kW class inverter for high-load motor applications
- 400V class suitable for industrial three-phase systems
- Variable speed control for process optimization and efficiency
- Supports smooth acceleration/deceleration control behavior
- Suitable for conveyors, pumps, and heavy auxiliary drives
- Reliable MX2 platform for OEM and retrofit projects
High-Power Variable Frequency Control for Heavy Industrial Loads
The 3G3MX2-A4110-V2 is designed for demanding motor applications where adjustable speed and process optimization are required. Its 11kW class supports heavier conveyors, pumps, and high-duty drive systems. As part of the MX2 series, it enables reliable commissioning, smooth motor behavior, and long-term maintainable deployment in industrial environments.
Typical Applications
- Controlling high-power conveyor drive systems
- Regulating pump speed in utility/process loops
- Managing fan and blower speed in production facilities
- Retrofitting fixed-speed motors to VFD operation
- Standardizing high-power drive channels in OEM lines
- Improving energy usage on variable-load motor applications
Buying Checklist
- High-power class supports demanding industrial duties
- Variable speed control improves process flexibility
- Can reduce mechanical stress on drive trains
- Strong fit for modernization and new machine platforms
- Reliable long-term choice for heavy-duty automation
Technical Specifications
| Model | 3G3MX2-A4110-V2 |
|---|---|
| Series | 3G3MX2 (MX2) |
| Rated Output | 11kW (15 HP) |
| Input Voltage | Three-phase 380-480VAC |
| Output Current | 25A (ND), 22A (HD) |
| Control Method | V/f, Sensorless Vector |
| Built-in EMC Filter | Yes |
| Communication | Modbus RTU |
| Brake Chopper | Built-in |
| Safety | STO |
| Operating Temperature | -10 to +50°C |
| Mounting | Panel mount |
| Mass | Approx. 5kg |
Frequently Asked Questions
What motor size can this drive?
11kW (15 HP) at 400V three-phase. Check motor nameplate full-load current - must not exceed VFD output current rating (25A ND, 22A HD).
Do I need input reactor?
For installations with high line distortion or weak supply, input reactor recommended. Protects VFD from line transients, reduces harmonic distortion. Required for installations with generator supply.
Can this VFD control high-inertia loads?
Yes, sensorless vector mode provides high starting torque (150% at 0.5 Hz). For very high-inertia loads, size VFD one size larger or extend acceleration time to prevent overcurrent faults.
What's the maximum cable length?
Motor cable: 50m shielded, 100m unshielded without output filter. With output reactor: up to 200m. With sine-wave filter: up to 500m. Longer cables cause voltage reflection.
