SKU: 3G3MX2-A4007-V2
Omron 3G3MX2-A4007-V2 MX2 Inverter 0.75kW 400V Three-Phase
Omron 3G3MX2-A4007-V2 is a 0.75kW MX2 series VFD with three-phase 400V input, compact design for small motor speed control applications.
USD 175.00 per unit, volume discounts available
- In stock, ships in 24h
- 100% genuine Omron
- 1-year manufacturer warranty
- Worldwide delivery
Key Features
- 0.75kW output power (1 HP)
- Three-phase 380-480V input
- Advanced vector control
- Built-in EMC filter
- Compact DIN rail mount
- Modbus RTU communication
- Detachable keypad
- Comprehensive protection
Omron MX2 3G3MX2-A4007-V2 0.75kW Variable Frequency Drive
The Omron 3G3MX2-A4007-V2 is a compact variable frequency drive from the MX2 series, delivering 0. 75kW output for three-phase 400V motor control applications. This inverter combines compact size with powerful features including advanced vector control, built-in EMC filter, and multiple communication options. The MX2 series is designed for easy integration with intuitive setup procedures and comprehensive parameter support. With operating frequencies up to 400Hz and precise speed control, the 3G3MX2-A4007-V2 is ideal for pumps, fans, conveyors, and general industrial machinery requiring efficient motor speed control. The drive supports multiple control modes including V/f control and sensorless vector control, providing flexibility for various application requirements. Built-in safety functions meeting SIL3 requirements provide additional protection for personnel and equipment. The comprehensive protection features include overload, overvoltage, undervoltage, overtemperature, and short circuit protection, ensuring reliable operation. The intuitive keypad with copy function simplifies setup and commissioning, while the compact DIN rail mounting design saves valuable panel space. Multiple communication options with Modbus RTU built-in enable seamless integration into automation systems.
Typical Applications
- Small pumps
- HVAC fans
- Mini conveyors
- Packaging machinery
- Textile equipment
- Food processing
- Laboratory equipment
- Small machine tools
Buying Checklist
- Compact space-saving design
- Energy efficient operation
- Easy installation and setup
- Built-in protection features
- Flexible communication
- Omron quality and support
- Cost-effective solution
- Reliable performance
Technical Specifications
| Model | 3G3MX2-A4007-V2 |
|---|---|
| Series | 3G3MX2 (MX2) |
| Type | Variable Frequency Drive (VFD) |
| Rated Output | 0.75kW (1 HP) |
| Input Voltage | Three-phase 380-480VAC |
| Output Current | 2.1A (ND), 1.7A (HD) |
| Control Method | V/f control, Sensorless Vector |
| Frequency Range | 0.1 to 400 Hz |
| Built-in EMC Filter | Yes (Class C2) |
| Communication | Modbus RTU (built-in) |
| I/O | 5 digital inputs, 3 digital outputs, 2 analog |
| Protection | Overcurrent, overvoltage, undervoltage, thermal |
| Brake Chopper | Built-in |
| Operating Temperature | -10 to +50°C |
| Mounting | DIN rail or panel |
| Dimensions | 70 x 128 x 113mm |
| Mass | Approx. 0.8kg |
| Keypad | Detachable LED |
| Safety | STO (Safe Torque Off) |
Frequently Asked Questions
What's the difference between ND and HD ratings?
ND (Normal Duty): 150% overload for 60 seconds, for pumps/fans. HD (Heavy Duty): 180% overload for 60 seconds, for conveyors/constant torque. Size HD for high starting torque applications.
Can I run single-phase motor with this VFD?
No, MX2 output is three-phase only. For single-phase motor speed control, use dedicated single-phase VFD or replace motor with three-phase. Input can be single or three-phase depending on model.
Do I need an output reactor?
For motor cable runs under 50m, no reactor needed (built-in EMC filter suffices). For 50-100m runs, add output reactor. Over 100m, use sine-wave filter. Long cables cause voltage reflection that can damage motor insulation.
How do I control speed from PLC?
Three methods: 1) Modbus RTU via RS-485 (most common), 2) Analog input (0-10V or 4-20mA), 3) Digital inputs (multi-step speed). Modbus allows speed control, monitoring, and parameter changes from PLC.
What braking options are available?
Built-in brake chopper accepts external brake resistor for dynamic braking. Calculate resistor value based on deceleration requirements and duty cycle. For holding brake (vertical axis), use motor-mounted electromagnetic brake.
