SKU: CJ2M-CPU33
Omron CJ2M-CPU33 PLC CPU Unit 20K Steps EtherNet/IP USB Built-in
Omron CJ2M-CPU33 is a CJ2M series PLC CPU unit with 20K program capacity, built-in EtherNet/IP and USB ports for machine automation and process control applications.
USD 330.00 per unit, volume discounts available
- In stock, ships in 24h
- 100% genuine Omron
- 1-year manufacturer warranty
- Worldwide delivery
Key Features
- Built-in EtherNet/IP port for network connectivity
- Base I/O capacity: 64 points, expandable to 2560 points
- Modular design supports wide range of CJ series I/O modules
- High-speed processing for complex logic and data handling
- Supports multiple communication protocols via option boards
- Hot-swappable I/O modules for reduced downtime
- Proven reliability in industrial environments
- Compatible with CX-Programmer and Sysmac Studio software
Flexible Modular Architecture for Scalable Automation
The Omron CJ2M-CPU33 is a mid-range modular PLC from the popular CJ2M series, designed for applications requiring flexibility and scalability. This CPU unit features built-in EtherNet/IP connectivity for seamless integration with HMIs, drives, and enterprise networks. The base unit supports 64 I/O points with expansion capability up to 2560 points using CJ series I/O modules. Its modular architecture allows you to customize the exact I/O configuration needed for your application, from simple digital I/O to specialized analog, temperature, and position control modules. The CJ2M-CPU33 is widely used in material handling, packaging, water treatment, and building automation systems where reliability and expandability are essential.
Typical Applications
- Water and wastewater treatment control systems
- Material handling and sorting equipment
- Building automation and HVAC control
- Food and beverage processing machinery
- Pharmaceutical manufacturing equipment
- Automotive assembly line control
- Retrofit projects replacing older CJ1 or CQM1 systems
Buying Checklist
- Determine total I/O requirements including future expansion needs
- Select appropriate power supply unit for backplane
- Verify EtherNet/IP compatibility with existing network infrastructure
- Choose compatible I/O modules (digital, analog, special function)
- Ensure programming software license is available (CX-Programmer)
- Consider redundancy requirements for critical applications
Technical Specifications
| Model | CJ2M-CPU33 |
|---|---|
| Series | CJ2M |
| Type | PLC CPU Unit |
| Program Capacity | 20K steps |
| Data Memory | 32K words |
| Built-in Ports | EtherNet/IP, USB |
| Max I/O Points | 2560 points |
| LD Instruction Time | 0.04μs |
| Motion Control | 2-axis pulse I/O (with module) |
| High-Speed Counter | 100kHz 2-axis |
| Interrupt Inputs | 4 points |
| Expandable Units | Up to 40 units |
| Battery Life | 5 years at 25°C |
| Operating Temperature | 0 to +55°C |
| Mounting | DIN rail or panel |
| Dimensions | 90 x 65 x 80mm |
| Mass | Approx. 280g |
Frequently Asked Questions
What are the main differences between CJ2M-CPU31/32/33/34/35?
The main difference is program capacity: CPU31=5K, CPU32=10K, CPU33=20K, CPU34=30K, CPU35=60K steps. All have built-in EtherNet/IP and USB. Choose based on your program size requirements and future expansion needs.
Can I use existing CJ1 modules with this CJ2M CPU?
Yes, the CJ2M is fully compatible with all existing CJ1 I/O units, control units, and communication modules. This makes it ideal for upgrading existing CJ1 systems without replacing all modules.
What software do I need to program this PLC?
CX-Programmer (part of CX-One suite) is required for ladder logic programming. For structured text or function block, use CX-Programmer with appropriate options. Sysmac Studio can also be used for newer projects.
Is this PLC suitable for motion control applications?
Yes, with optional pulse I/O modules, the CJ2M can control up to 4 axes of stepper or servo motors. For more advanced motion control, consider the NJ series machine automation controllers with integrated motion.
How do I connect this PLC to an HMI or SCADA system?
Use the built-in EtherNet/IP port for modern HMI/SCADA connections. For legacy systems, add a serial communication module (RS-232C/RS-422/RS-485) for Modbus RTU or Host Link protocol connections.
