SKU: CP1W-TS102
Omron CP1W-TS102 Platinum Resistance Input Unit 2-Channel
Omron CP1W-TS102 is a 2-channel platinum resistance (Pt100) input expansion unit for CP1 series PLCs.
USD 88.00 per unit, volume discounts available
- In stock, ships in 24h
- 100% genuine Omron
- 1-year manufacturer warranty
- Worldwide delivery
Key Features
- Thermocouple input capability for CP1 PLC platforms
- Supports accurate temperature acquisition for control logic
- Suitable for ovens, heaters, and thermal process modules
- Improves quality control through better thermal visibility
- Useful in retrofit temperature monitoring upgrades
- Practical module for standardized thermal system design
Accurate Thermal Input Expansion for CP1 Process Monitoring
The CP1W-TS102 enables CP1 controllers to acquire thermocouple signals for closed-loop monitoring and thermal alarms in machine processes. It is suitable for packaging heaters, drying ovens, and utility thermal systems where temperature consistency directly affects quality. This module supports maintainable PLC-based thermal architecture in both new and retrofit projects.
Typical Applications
- Monitoring sealing heater temperatures in packaging lines
- Reading oven zones for process stability
- Implementing thermal alarms in utility heating systems
- Adding temperature feedback in CP1 retrofit panels
- Standardizing thermocouple input across OEM machines
- Improving thermal process consistency and traceability
Buying Checklist
- Direct CP1 integration simplifies architecture
- Accurate thermal data supports higher product quality
- Useful for both new machine builds and upgrades
- Supports maintainable long-term temperature monitoring
- Strong fit for thermal process automation applications
Technical Specifications
| Model | CP1W-TS102 |
|---|---|
| Series | CP1W |
| Type | Platinum Resistance Input Unit |
| Input Channels | 2 channels |
| Input Types | Pt100, JPt100 |
| Temperature Range | -200 to +600°C (Pt100) |
| Resolution | 0.01°C |
| Accuracy | ±0.3% full scale ±1 digit |
| Conversion Time | 500ms per channel |
| Connection | Removable terminal block |
| Current Consumption | 100mA at 5VDC |
| Compatible CPUs | CP1E, CP1L, CP1H |
| Operating Temperature | 0 to +55°C |
Frequently Asked Questions
What's the advantage of Pt100 vs thermocouple?
Pt100: higher accuracy (±0.3% vs ±0.5%), better stability, no cold junction compensation needed. Thermocouple: wider temperature range, lower cost. Choose Pt100 for precision, thermocouple for high temperature.
What wiring configuration?
2-wire, 3-wire, or 4-wire Pt100. 3-wire most common (compensates lead resistance). 4-wire highest accuracy. Configure in CX-Programmer.
How accurate is Pt100 measurement?
±0.3% of full scale ±1 digit. For 0-200°C range: approximately ±0.6°C accuracy. Higher accuracy than thermocouple for same temperature range.
What wire should I use?
Use Pt100 extension wire or copper wire. Keep wire resistance balanced for 3-wire configuration. Follow wiring diagram in manual.
