SKU: E2EC-C1R5D1
Omron E2EC-C1R5D1 Capacitive Proximity Sensor
Omron E2EC-C1R5D1 is a capacitive proximity sensor for detecting metallic and non-metallic objects including liquids and granular materials.
USD 58.00 per unit, volume discounts available
- In stock, ships in 24h
- 100% genuine Omron
- 1-year manufacturer warranty
- Worldwide delivery
Key Features
- Sensing Distance: Adjustable up to 15mm
- Output Type: NPN Open Collector
- Supply Voltage: DC12-24V
- Load Current: 100mA
- Response Time: 50ms
- Sensitivity: Adjustable potentiometer
Reliable Detection Layer for Sequence Accuracy and Process Stability
The E2EC-C1R5D1 is used to deliver repeatable machine-state detection for sequencing, interlocks, and process confirmation. Whether in packaging, handling, or assembly systems, this sensing class helps reduce false triggers and improves control confidence under continuous operation.
Repeatable State Detection
Accurate detection at the right process moment improves sequence integrity and reduces quality escapes caused by timing uncertainty or missed events.
Fit for Demanding Machine Environments
Industrial sensing components are selected for stability under vibration, contamination, and repetitive duty where consumer-grade devices are not suitable.
Faster Commissioning and Replacement
Standardized sensor families simplify spare strategy, reduce replacement errors, and support quicker return to production after maintenance events.
Typical Applications
- Provides stable detection signals to PLC logic
- Improves sequence timing accuracy
- Reduces dependence on mechanical contact methods
- Supports high-cycle production operation
- Enables better fault isolation at machine stations
- Simplifies maintenance through standard sensor families
Buying Checklist
- Repeatable industrial detection behavior
- Designed for continuous machine duty
- Improves process timing confidence
- Serviceable and standardizable selection
- Reliable fit for automation sensing layers
Technical Specifications
| Model | E2EC-C1R5D1 |
|---|---|
| Series | E2EC |
| Type | Capacitive Proximity Sensor |
| Sensing Distance | Adjustable up to 15mm |
| Output Type | NPN Open Collector |
| Supply Voltage | DC12-24V |
| Load Current | 100mA |
| Response Time | 50ms |
| Sensitivity | Adjustable potentiometer |
| Cable Length | 2m |
| Protection | IP64 |
| Operating Temperature | -25 to +70°C |
| Detectable Objects | Metal, plastic, wood, glass, liquids |
Frequently Asked Questions
What materials can capacitive sensors detect?
All materials: metal, plastic, wood, glass, ceramics, liquids, granular materials. Detection depends on dielectric constant of material. Higher dielectric = easier detection.
How do I adjust sensitivity?
Use potentiometer on sensor side. Turn clockwise to increase sensitivity (detect through thicker barriers), counter-clockwise to decrease. Adjust while monitoring operation LED.
Can this sensor detect through barriers?
Yes, capacitive sensors can detect through non-metallic barriers (plastic, glass, wood). Useful for level detection through tank walls or detecting contents through packaging.
What applications use capacitive sensors?
Liquid level detection, powder/granular level, non-metallic part detection, presence detection through packaging, material identification based on dielectric constant.
