SKU: E3X-HD41
Omron E3X-HD41 Digital Fiber Amplifier High-Speed
Omron E3X-HD41 is a high-speed digital fiber amplifier for fiber optic sensors with advanced detection capabilities.
USD 51.00 per unit, volume discounts available
- In stock, ships in 24h
- 100% genuine Omron
- 1-year manufacturer warranty
- Worldwide delivery
Key Features
- Light Source: Red LED
- Supply Voltage: DC12-24V
- Output: NPN open collector
- Response Time: 50μs (ultra-high-speed mode)
- Fiber Connection: M3 threaded
- Indicators: Operation LED, stability LED
Reliable Detection Layer for Sequence Accuracy and Process Stability
The E3X-HD41 is used to deliver repeatable machine-state detection for sequencing, interlocks, and process confirmation. Whether in packaging, handling, or assembly systems, this sensing class helps reduce false triggers and improves control confidence under continuous operation.
Repeatable State Detection
Accurate detection at the right process moment improves sequence integrity and reduces quality escapes caused by timing uncertainty or missed events.
Fit for Demanding Machine Environments
Industrial sensing components are selected for stability under vibration, contamination, and repetitive duty where consumer-grade devices are not suitable.
Faster Commissioning and Replacement
Standardized sensor families simplify spare strategy, reduce replacement errors, and support quicker return to production after maintenance events.
Typical Applications
- Provides stable detection signals to PLC logic
- Improves sequence timing accuracy
- Reduces dependence on mechanical contact methods
- Supports high-cycle production operation
- Enables better fault isolation at machine stations
- Simplifies maintenance through standard sensor families
Buying Checklist
- Repeatable industrial detection behavior
- Designed for continuous machine duty
- Improves process timing confidence
- Serviceable and standardizable selection
- Reliable fit for automation sensing layers
Technical Specifications
| Model | E3X-HD41 |
|---|---|
| Series | E3X |
| Type | Digital Fiber Amplifier |
| Light Source | Red LED |
| Supply Voltage | DC12-24V |
| Output | NPN open collector |
| Response Time | 50μs (ultra-high-speed mode) |
| Fiber Connection | M3 threaded |
| Indicators | Operation LED, stability LED |
| Sensitivity | Digital adjustment, teach function |
| Display | 4-digit LED |
| Operating Temperature | -25 to +55°C |
| Mounting | DIN rail |
Frequently Asked Questions
What's the advantage of digital fiber amplifier?
Digital adjustment (no potentiometer), teach function for automatic sensitivity setting, stability indicator, fault detection, remote teaching capability. More precise and repeatable than analog.
What's ultra-high-speed mode?
50μs response time (20kHz response). For high-speed detection: counting small parts, detecting fast-moving objects, high-speed packaging. Standard mode: 0.5ms for general applications.
How does teach function work?
Two methods: 1) Two-point teach: place target, press teach, remove target, press teach. 2) One-point teach: press teach with target present, amplifier sets optimal sensitivity automatically.
Can I connect multiple amplifiers?
Yes, E3X series supports mutual interference prevention. Multiple amplifiers can be mounted side-by-side without cross-talk.
