SKU: E3X-NA11 2M
Omron E3X-NA11 2M Digital Fiber Amplifier 2m Cable
Omron E3X-NA11 2M is a digital fiber amplifier with 2m cable for fiber optic sensors with digital sensitivity adjustment.
USD 22.00 per unit, volume discounts available
- In stock, ships in 24h
- 100% genuine Omron
- 1-year manufacturer warranty
- Worldwide delivery
Key Features
- Fiber optic amplification for compact high-precision sensing
- Suitable for small target and constrained-space applications
- Supports repeatable detection in high-cycle automation
- Practical integration with compatible fiber heads
- Useful for packaging, electronics, and assembly tasks
- Reliable sensor architecture for precision production lines
Flexible Fiber Amplification for Precision Sensing in Tight Installations
The E3X-NA11 2M supports fiber-based detection where conventional sensors cannot achieve required geometry or sensitivity. It is suitable for small-part detection, edge monitoring, and high-speed event triggering in automated production lines. This amplifier provides practical configuration flexibility for OEM builders and maintenance teams managing precision sensing systems.
Typical Applications
- Detecting miniature parts on fast feeder lines
- Monitoring precise edge position in compact fixtures
- Triggering quality checks in high-speed assembly steps
- Replacing bulky sensors in constrained machine sections
- Standardizing fiber detection points in OEM builds
- Improving repeatability of difficult optical detection tasks
Buying Checklist
- Fiber approach solves tough installation and geometry constraints
- Strong sensitivity supports high-precision automation
- Flexible integration improves machine design options
- Useful for modernization of legacy sensing points
- Reliable option for quality-critical production detection
Technical Specifications
| Model | E3X-NA11 2M |
|---|---|
| Series | E3X |
| Type | Digital Fiber Amplifier |
| Light Source | Red LED |
| Supply Voltage | DC12-24V |
| Output | NPN open collector |
| Response Time | 0.5ms |
| Cable Length | 2m |
| Fiber Connection | M3 threaded |
| Sensitivity | Digital adjustment, teach function |
| Display | LED indicators |
| Operating Temperature | -25 to +55°C |
Frequently Asked Questions
What's the difference between E3X-HD and E3X-NA?
E3X-HD: high-speed (50μs), 4-digit display, advanced features. E3X-NA: standard speed (0.5ms), LED indicators, cost-effective. Choose HD for high-speed, NA for general applications.
Does this amplifier have teach function?
Yes, one-point teach function. Press teach button with target present, amplifier automatically sets optimal sensitivity.
What fiber cables work with this amplifier?
All E32 series fiber cables with M3 connection. Through-beam, diffuse, coaxial, area beam. Choose fiber type based on application.
How do I know if sensitivity is set correctly?
Stability LED indicates signal margin. Green: good margin. Red: insufficient margin, adjust sensitivity or check fiber alignment.
