Omron E6B2-CWZ6C 300P-R Rotary Encoder 300P/R DC5-24V NPN Φ40mm
Omron E6B2-CWZ6C 300P-R is a φ40mm incremental rotary encoder with 300 PPR resolution, DC5-24V supply voltage, NPN open collector output for general motor speed feedback and conveyor monitoring applications.
USD 32.00 per unit, volume discounts available
- In stock, ships in 24h
- 100% genuine Omron
- 1-year manufacturer warranty
- Worldwide delivery
Key Features
- φ40mm incremental encoder
- 300 PPR resolution
- DC5-24V supply
- NPN open collector output
- A/B/Z phases
Omron E6B2-CWZ6C 300P/R Rotary Encoder
The Omron E6B2-CWZ6C 300P-R is an incremental rotary encoder from the E6B2-C series with 300 pulses per revolution resolution. This φ40mm encoder features NPN open collector output with A/B/Z phases and operates on DC5-24V supply. The 300 PPR resolution is suitable for general-purpose motor speed monitoring and basic position feedback applications.
Typical Applications
- Supports reliable machine operation
- Improves integration consistency across projects
- Contributes to service-friendly panel design
- Helps reduce lifecycle support complexity
- Supports production uptime objectives
- Enables practical modernization paths
Buying Checklist
- Industrial-grade integration reliability
- Supports maintainable automation design
- Improves production stability objectives
- Practical fit for OEM and retrofit use
- Useful for long-term lifecycle planning
Technical Specifications
| Model | E6B2-CWZ6C 300P-R |
|---|---|
| Series | E6B2-C |
| Type | Incremental Rotary Encoder |
| Body Diameter | Φ40mm |
| Shaft Diameter | Φ6mm |
| Resolution | 300 P/R |
| Output Phase | A/B/Z (3-phase) |
| Output Type | NPN Open Collector |
| Supply Voltage | DC5-24V ±10% |
| Max Response Frequency | 100kHz |
| Max Rotational Speed | 6000rpm |
| Cable Length | 0.5m |
| Protection Rating | IP50 |
| Operating Temperature | -10 to +70°C |
| Starting Torque | 0.9mN·m max |
Frequently Asked Questions
What is the resolution?
300 pulses per revolution (PPR), suitable for general motor speed monitoring, conveyor speed feedback, and applications where medium resolution is sufficient.
What supply voltage does this encoder require?
DC5-24V wide range supply (±10% tolerance), compatible with most PLC counter inputs and industrial control systems. Current consumption is 80mA maximum at 24VDC.
Is there a 2m cable version available?
Yes, order E6B2-CWZ6C 300P-R 2M for the 2-meter cable version, which provides extended installation reach without requiring extension cables.
What is the output type?
NPN open collector output (sinking type), compatible with most PLC high-speed counter inputs. Requires pull-up resistors if your PLC input doesn't have internal pull-ups.
