SKU: NS10-TV00B-V2
Omron NS10-TV00B-V2 HMI Touchscreen 10.4 inch TFT Color Ethernet
Omron NS10-TV00B-V2 is a 10.4 inch TFT color HMI touchscreen with Ethernet connectivity for advanced machine visualization and operator interface applications.
USD 730.00 per unit, volume discounts available
- In stock, ships in 24h
- 100% genuine Omron
- 1-year manufacturer warranty
- Worldwide delivery
Key Features
- Touchscreen HMI control interface for machine operation
- Dual Ethernet ports for enhanced network integration
- Suitable for alarm, status, and recipe workflow screens
- Supports complex multi-station visualization requirements
- Improves operator usability and troubleshooting speed
- Practical modernization path from legacy HMI panels
Operator-Centric HMI Control for Connected Automation Systems
The NS10-TV00B-V2 provides interactive machine control and process visualization for applications requiring clear operator access to alarms, status, and recipes. Dual Ethernet connectivity supports broader integration with controllers and supervisory systems. This unit is suitable for high-function packaging, robotics, and production equipment where interface quality directly affects uptime.
Typical Applications
- Displaying machine status and alarms to operators
- Managing production recipes and parameter adjustments
- Connecting HMI with PLC and supervisory network layers
- Supporting advanced visualization for multi-cell machines
- Replacing obsolete operator panels in retrofit projects
- Standardizing operator interface quality across OEM lines
Buying Checklist
- Dual Ethernet improves integration flexibility
- Enhances operator workflow with clear touchscreen control
- Supports better troubleshooting through richer visualization
- Good fit for modern connected machine architectures
- Strong value for interface modernization initiatives
Technical Specifications
| Model | NS10-TV00B-V2 |
|---|---|
| Series | NS10 |
| Type | Programmable Terminal (HMI) |
| Screen Size | 10.4 inch |
| Display Type | TFT Color LCD |
| Resolution | 640 x 480 pixels (VGA) |
| Touch Panel | Analog resistive |
| Communication Ports | Ethernet, RS-232C, RS-422A/485 |
| PLC Connectivity | Omron, Allen-Bradley, Siemens, Mitsubishi, etc. |
| Memory | 16MB program, 8MB data |
| Supply Voltage | DC24V |
| Power Consumption | 30W max |
| Protection Rating | IP65 (front panel) |
| Operating Temperature | 0 to +55°C |
| Mounting | Panel mount |
| Dimensions | 270 x 207 x 57mm |
| Mass | Approx. 1.5kg |
| Software | CX-Designer |
| Data Logging | CF card slot |
Frequently Asked Questions
What PLCs can this HMI connect to?
NS series supports 200+ PLC drivers including Omron (CJ, CP, NJ, NX), Allen-Bradley (ControlLogix, CompactLogix), Siemens (S7-300/400/1200/1500), Mitsubishi (FX, Q, iQ-R), Schneider, and many more via Ethernet, serial, or fieldbus.
What's the difference between NS10, NS12, and NS15?
Screen size and resolution: NS10=10.4" VGA (640x480), NS12=12.1" SVGA (800x600), NS15=15" XGA (1024x768). Larger screens show more data simultaneously but cost more. Choose based on information density needs and panel space.
How do I transfer programs to this HMI?
Three methods: 1) Ethernet (fastest, recommended), 2) CF card (for field updates without PC), 3) RS-232C serial (legacy). CX-Designer software manages transfers. Ethernet allows remote programming and monitoring.
Can this HMI log data to a database?
Yes, via Ethernet: log to CSV on CF card, FTP server, or directly to SQL database (with scripting). Common applications: production tracking, quality data collection, maintenance records, and OEE monitoring.
Is this HMI suitable for harsh environments?
Front panel is IP65 (dust-tight, water jet resistant). Operating temperature 0 to +55°C. For harsher conditions, consider stainless steel HMI models or add protective enclosure. Avoid direct sunlight on display.
