Omron NS5-SQ10B-V2 NS Series HMI 5.7 inch STN Color Display
Omron NS5-SQ10B-V2 is a compact 5.7 inch STN color HMI with Ethernet connectivity for space-constrained machine operator interfaces.
USD 410.00 per unit, volume discounts available
- In stock, ships in 24h
- 100% genuine Omron
- 1-year manufacturer warranty
- Worldwide delivery
Key Features
- NS-series 5.7-inch class operator interface
- Supports machine control, alarms, and diagnostics
- Suitable for recipe and parameter entry workflows
- Integrates with PLC tag-based communication structures
- Fits compact cabinet door layouts
- Common choice for retrofit UI modernization
Compact NS HMI for Daily Operation and Diagnostics
NS5-SQ10B-V2 is part of Omron NS HMI lineup and is widely used in compact and mid-size machines for operator commands, alarm handling, and process visibility. A 5. 7-inch interface is a practical choice when panel space is constrained but clear screen interaction is still required. This model is often used for mode selection, recipe management, maintenance pages, and production counters in packaging and assembly systems. During implementation, teams should confirm communication mapping, alarm priority design, and user-permission structure to support safe and efficient operation. Panel cutout precision and environmental suitability should be checked before installation. NS5-SQ10B-V2 is typically chosen where robust operator workflow and maintainable screen architecture are required across multiple deployed machine units.
Typical Applications
- Operator start stop and mode selection screens
- Alarm list and fault acknowledgment workflows
- Recipe and setpoint entry during changeovers
- Maintenance diagnostic and manual-control pages
- Production counters and runtime status views
- Legacy HMI replacement in existing machine lines
Buying Checklist
- Validate required UI complexity for 5.7-inch screen size.
- Confirm communication compatibility with existing controller.
- Check panel cutout dimensions and clearance depth.
- Define user roles and password policy before deployment.
- Back up project files for rapid service recovery.
Technical Specifications
| Model | NS5-SQ10B-V2 |
|---|---|
| Series | NS5 |
| Screen Size | 5.7 inch |
| Display Type | STN Color LCD |
| Resolution | 320 x 240 pixels (QVGA) |
| Communication | Ethernet, RS-232C |
| Supply Voltage | DC24V |
| Protection | IP65 front panel |
| Operating Temperature | 0 to +55°C |
| Dimensions | 170 x 132 x 57mm |
| Software | CX-Designer |
Frequently Asked Questions
When should I choose 5.7" compact HMI?
Choose 5.7" for: small machines with limited panel space, simple operator interface (start/stop, setpoint, status), cost-sensitive applications, or distributed HMIs (one per machine station).
What's the difference between STN and TFT displays?
STN: lower cost, slower response, narrower viewing angle. TFT: better image quality, faster response, wider viewing angle, higher cost. For most HMI applications, STN is adequate. Choose TFT for fast-changing displays or wide viewing angle requirements.
Can this compact HMI connect to Ethernet?
Yes, NS5-SQ10B-V2 has built-in Ethernet port for PLC connectivity, data logging, and remote access. Same connectivity as larger NS models in compact form factor.
How many screens can I create?
NS5 supports up to 800 screens (more than typical applications need). Limited by 16MB program memory. For most machines, 20-50 screens is typical.
