SKU: NX1P2-9024DT
Omron NX1P2-9024DT NX Series Compact PLC Controller
Compact PLC with 14 inputs, 10 NPN outputs, EtherCAT and EtherNet/IP connectivity for high-speed machine automation
USD 242.00 per unit, volume discounts available
- In stock, ships in 24h
- 100% genuine Omron
- 1-year manufacturer warranty
- Worldwide delivery
Key Features
- 14 digital inputs (PNP/NPN selectable) and 10 NPN transistor outputs
- Dual communication ports: EtherCAT master and EtherNet/IP adapter
- High-speed processing with instruction execution time as fast as 1ns
- Compact design reduces panel space while maintaining full functionality
- Built-in cybersecurity with user authentication and access control
- Supports up to 128 axes of synchronized motion control
- Direct database connectivity without additional hardware
- Wide operating temperature range: 0C to 55C
High-Performance Compact Controller for Precision Automation
The Omron NX1P2-9024DT is a compact yet powerful PLC from the NX1 Series, designed for small to mid-size machines requiring precise control and fast response. This controller integrates logic, motion, and communication capabilities in a space-saving design. With dual communication ports supporting both EtherCAT and EtherNet/IP protocols, it enables seamless integration with servo drives, inverters, HMIs, and enterprise systems. The unit features 14 digital inputs (PNP/NPN selectable) and 10 NPN transistor outputs, making it ideal for packaging, assembly, and material handling applications. Its high-speed processing executes basic instructions in nanoseconds, ensuring precise timing for critical operations. Built-in cybersecurity features including user authentication protect your automation assets from unauthorized access.
Typical Applications
- Packaging machinery requiring precise timing and synchronization
- Small to mid-size assembly machines with motion control needs
- Material handling systems with conveyor coordination
- Food processing equipment requiring compact, hygienic design
- Semiconductor manufacturing equipment
- Battery production machinery
- Retrofit projects upgrading from legacy CP/CJ series controllers
Buying Checklist
- Confirm I/O requirements: 14 inputs and 10 outputs may need expansion for larger machines
- Verify communication protocol compatibility with existing devices (EtherCAT vs EtherNet/IP)
- Ensure Sysmac Studio software is available for programming and commissioning
- Consider power supply capacity: 24VDC required with adequate current rating
- Check panel dimensions and DIN rail space for proper fit
- For motion control applications, verify axis count does not exceed 128
- Plan for adequate ventilation to maintain operating temperature below 55C
Technical Specifications
| Series | NX1P |
|---|---|
| Program Memory | 1.5 MB |
| Digital Inputs | 14 points (PNP/NPN selectable) |
| Digital Outputs | 10 points (NPN transistor) |
| I/O Capacity | Up to 2560 points with remote I/O expansion |
| Communication Ports | 2x Ethernet (1x EtherCAT, 1x EtherNet/IP) |
| Instruction Execution Time | 1ns (basic instructions) |
| Power Supply Voltage | 24VDC |
| Operating Temperature | 0C to 55C (32F to 131F) |
| Mounting | DIN rail mount |
| Programming Software | Sysmac Studio |
| Motion Control Axes | Up to 128 axes |
| Dimensions | Compact footprint for space-constrained panels |
Frequently Asked Questions
What is the difference between NX1P2-9024DT and NX1P2-9024DT1?
The suffix indicates output type and connector details. DT models have NPN transistor outputs with terminal block connectors, while DT1 variants may have different connector types or PNP outputs. Always verify the complete SKU when ordering replacements.
Can the NX1P2-9024DT control servo motors directly?
Yes, through the EtherCAT master port. It can control up to 128 axes of servo motion when connected to EtherCAT servo drives. The controller provides synchronized motion control suitable for complex multi-axis applications.
Is Sysmac Studio software included or sold separately?
Sysmac Studio is typically sold separately. You can download a trial version from the Omron website, but a valid license is required for full programming and commissioning features.
What is the maximum expansion I/O capacity?
The NX1P2-9024DT supports up to 2560 I/O points when using remote I/O expansion via EtherCAT. This allows significant flexibility for larger machine applications.
Can this controller replace older CJ or CP series PLCs?
Yes, the NX1P2-9024DT is commonly used as an upgrade path from CJ2M and CP1E series controllers. It offers superior performance, more I/O capacity, and modern communication protocols. Contact us for migration support and compatibility verification.
