SKU: 3G3MX2-AB015-V2
Omron 3G3MX2-AB015-V2 MX2 Inverter Drive 1.5kW 230V
Omron 3G3MX2-AB015-V2 is a 1.5kW MX2 VFD with 230V single/three-phase input for medium-power motor speed control applications.
USD 180.00 per unit, volume discounts available
- In stock, ships in 24h
- 100% genuine Omron
- 1-year manufacturer warranty
- Worldwide delivery
Key Features
- 1.5kW inverter class for medium-duty motor applications
- 230V class integration for common machine installations
- Supports variable speed and acceleration profile tuning
- Suitable for conveyors, pumps, and general automation drives
- Improves process flexibility versus fixed-speed operation
- Reliable MX2 platform for OEM and retrofit adoption
Medium-Power Variable Speed Control for Efficient Machine Operation
The 3G3MX2-AB015-V2 enables precise motor speed adjustment in conveyors, pumps, and processing equipment where stable control and energy optimization are important. Its 1. 5kW class is widely applicable in compact-to-medium machine systems. As part of the MX2 family, it supports practical commissioning and maintainable lifecycle deployment.
Typical Applications
- Controlling conveyor speed in packaging cells
- Adjusting pump operation for process balance
- Managing fan speed in cooling and ventilation systems
- Upgrading contactor-driven motors to VFD control
- Standardizing medium-power drives in OEM equipment
- Improving efficiency in variable-load motor applications
Buying Checklist
- 1.5kW class covers many common industrial drive needs
- Variable-speed control improves process performance
- Can reduce mechanical stress and wear on equipment
- Good balance of capability and integration simplicity
- Practical long-term drive standard for machine builders
Technical Specifications
| Model | 3G3MX2-AB015-V2 |
|---|---|
| Series | 3G3MX2 (MX2) |
| Rated Output | 1.5kW (2 HP) |
| Input Voltage | Single/Three-phase 200-240VAC |
| Output Current | 7A (ND), 5.5A (HD) |
| Control Method | V/f, Sensorless Vector |
| Built-in EMC Filter | Yes |
| Communication | Modbus RTU |
| Brake Chopper | Built-in |
| Safety | STO |
| Operating Temperature | -10 to +50°C |
Frequently Asked Questions
What size motor can this VFD drive?
1.5kW (2 HP) at 400V three-phase, approximately 1.1kW (1.5 HP) on single-phase input. Check motor nameplate full-load current - must not exceed VFD output current rating.
Can I use this for conveyor applications?
Yes, sensorless vector mode provides high starting torque (150% at 0.5 Hz) for conveyor starting under load. Set acceleration time to prevent belt slip. Consider brake resistor for controlled stopping.
How do I reduce electromagnetic interference?
Use shielded motor cable with shield grounded at both ends, keep control wiring separate from power wiring (minimum 200mm separation), install input reactor if experiencing interference with other equipment.
What maintenance does this VFD require?
Minimal maintenance: check cooling fan operation annually, clean air filters (if equipped), check terminal tightness during first year, monitor for fault history. Expected life: 10+ years at rated conditions.
