Omron CJ1W-DA08V Analog Output Unit 8-Channel 0-10V

Omron CJ1W-DA08V Analog Output Module

The Omron CJ1W-DA08V is an 8-channel analog output module designed for CJ1 series programmable logic controllers, providing precise analog voltage signals for process control and automation applications. This module outputs 0-10VDC voltage signals, suitable for controlling variable frequency drives, analog actuators, indicators, and other devices requiring analog control inputs. Each of the 8 channels provides independent output with 12-bit resolution, ensuring smooth and accurate control signals for precise process regulation. The CJ1W-DA08V connects directly to the CJ1 backplane, drawing operating power from the PLC power supply while providing isolated analog outputs. The module includes comprehensive protection features including short circuit protection on each output channel, safeguarding both the module and connected field devices. LED status indicators provide at-a-glance monitoring of output activity. Easy configuration is achieved through CX-Programmer, allowing straightforward setup of output ranges and scaling. The CJ1W-DA08V supports various output ranges including 0-10VDC, making it compatible with a wide range of industrial control devices. Applications include VFD speed control, valve position control, analog indicator driving, process loop control, and any application requiring multiple analog output signals from the PLC.
