SKU: CJ1W-TC001
Omron CJ1W-TC001 Thermocouple Input Unit 1-Channel
Omron CJ1W-TC001 is a 1-channel thermocouple input unit for CJ series PLCs, with cold junction compensation for temperature measurement.
USD 160.00 per unit, volume discounts available
- In stock, ships in 24h
- 100% genuine Omron
- 1-year manufacturer warranty
- Worldwide delivery
Key Features
- 1-channel thermocouple input in CJ modular form
- Direct integration with Omron CJ-series PLC architecture
- Suitable for machine sections with critical thermal checkpoints
- Supports stable temperature data acquisition for control logic
- Reduces need for separate external temperature interface devices
- Useful in retrofit and maintenance of thermal process equipment
Single-Channel Temperature Input for Precision Process Supervision
The CJ1W-TC001 adds focused temperature measurement capability to CJ-based control platforms where one critical thermal zone must be monitored accurately. It is suitable for machines using heaters, ovens, or thermal conditioning steps that require dependable feedback to PLC logic. By integrating thermocouple measurement directly in the control rack, the module helps reduce external interface complexity and improves overall maintainability of temperature-aware automation systems.
Typical Applications
- Monitoring heater block temperature in sealing machines
- Reading oven zone temperature in curing or drying processes
- Supervising hot plate temperature in assembly stations
- Controlling thermal setpoints in packaging equipment
- Adding temperature feedback to retrofit CJ control panels
- Capturing process temperature for quality traceability logic
Buying Checklist
- Adds focused thermal sensing without major system redesign
- Ideal when one reliable temperature channel is needed
- CJ-native integration lowers commissioning overhead
- Supports better product quality through tighter temperature visibility
- Good maintenance replacement path for installed CJ systems
Technical Specifications
| Model | CJ1W-TC001 |
|---|---|
| Series | CJ1W |
| Type | Thermocouple Input Unit |
| Input Channels | 1 channel |
| Input Types | K, J, T, E, L, U, N, R, S, B, PLII |
| Temperature Range | -200 to +1800°C (depends on TC type) |
| Resolution | 0.1°C or 0.1°F |
| Accuracy | ±0.3% full scale ±1 digit |
| Conversion Time | 250ms per channel |
| Cold Junction Compensation | Automatic (internal) |
| Isolation | Channel-to-channel isolated |
| Connection | Removable terminal block |
| Current Consumption | 100mA at 5VDC |
| Operating Temperature | 0 to +55°C |
Frequently Asked Questions
What thermocouple types are supported?
K (most common, -200 to +1200°C), J (-200 to +900°C), T (-200 to +400°C), E, L, U, N, R, S, B (high temperature up to 1800°C). Select type in unit setup.
Do I need external cold junction compensation?
No, CJ1W-TC001 has built-in cold junction compensation. Unit measures terminal block temperature and compensates automatically. Ensures accurate temperature reading.
What wire should I use for thermocouple connection?
Use thermocouple extension wire (same type as sensor) or copper wire for short runs. Keep wire away from noise sources. Use terminal block for secure connection.
How accurate is this temperature measurement?
±0.3% of full scale ±1 digit. For K-type (0-1000°C range): approximately ±3°C accuracy. For higher accuracy, consider platinum resistance (Pt100) input units.
