SKU: D4BL-2CRA
Omron D4BL-2CRA Safety Door Switch with Lock Metal Housing
Omron D4BL-2CRA is a safety door switch with solenoid lock, metal housing for harsh environment safety guarding applications.
USD 135.00 per unit, volume discounts available
- In stock, ships in 24h
- 100% genuine Omron
- 1-year manufacturer warranty
- Worldwide delivery
Key Features
- Heavy-duty safety locking switch construction
- IP67 protection for demanding industrial environments
- 24VDC class integration for safety control panels
- Supports guard lock and interlock monitoring functions
- Suitable for controlled access machine safety systems
- Reliable operation in repetitive industrial duty
Locking Safety Switch for Controlled Access and Machine Protection
The D4BL-2CRA combines guard status monitoring with robust locking functionality to prevent unsafe access during hazardous machine conditions. It is suitable for production systems requiring controlled door release and dependable interlock behavior. This switch supports compliance-focused safety architecture in OEM machines and retrofit guarding upgrades.
Typical Applications
- Locking machine access doors during hazardous motion
- Monitoring guard lock state in safety circuits
- Implementing controlled release safety workflows
- Upgrading non-locking guards in retrofit projects
- Standardizing locking interlock hardware across OEM platforms
- Improving machine guarding reliability and compliance readiness
Buying Checklist
- Combines locking and sensing in one safety device
- Rugged IP67 build supports tough industrial duty
- Supports stronger controlled-access safety architectures
- Practical for both new builds and safety upgrades
- Reliable component for long-term guarding strategies
Technical Specifications
| Model | D4BL-2CRA |
|---|---|
| Series | D4BL |
| Type | Safety Door Switch with Guard Lock |
| Contact Form | 3NC (safety) + 1NO (auxiliary) |
| Lock Type | Solenoid release |
| Lock Force | 1000N |
| Enclosure | Die-cast aluminum |
| Protection Rating | IP67 |
| Safety Category | Category 4, PL e |
| Solenoid Voltage | 24VDC |
Frequently Asked Questions
What's the advantage of metal housing?
Metal housing provides: better mechanical protection against impact, higher temperature resistance, better EMI/RFI shielding, and longer life in harsh industrial environments. Choose for demanding applications.
Why 3NC instead of 4NC?
3NC provides triple redundancy for safety circuit (sufficient for Category 4). 4NC provides quad redundancy. Both achieve Category 4/PL e when properly applied. 3NC is more cost-effective for most applications.
What's the lock force rating?
1000N (100kg/220lbs) holding force. Sufficient for most guard locking applications. For higher force requirements (large guards, high-risk), consider D4NL series with 1300N rating.
Can this be used outdoors?
Yes, IP67 rating and metal housing suit outdoor use. Ensure conduit entries are properly sealed. Consider stainless steel version for corrosive environments (marine, chemical).
