Omron E6CP-AG5C 256P-R Absolute Rotary Encoder 256P Gray Code DC5-24V Φ40mm
Omron E6CP-AG5C 256P-R is a Φ40mm absolute rotary encoder with 256 PPR Gray code output, DC5-24V supply for absolute position detection without homing in robotics, valve positioning, and indexing applications.
USD 63.00 per unit, volume discounts available
- In stock, ships in 24h
- 100% genuine Omron
- 1-year manufacturer warranty
- Worldwide delivery
Key Features
- φ40mm absolute encoder
- 256 PPR Gray code output
- DC5-24V supply
- Absolute position detection
- No homing required
Omron E6CP-AG5C Absolute Rotary Encoder
The Omron E6CP-AG5C is an absolute rotary encoder providing 256 pulses per revolution with Gray code output. Unlike incremental encoders, absolute encoders provide unique position information at any point without needing to return to a home position. This φ40mm encoder operates on DC5-24V supply and is ideal for applications requiring absolute position knowledge such as robotic joints, valve positioning, and multi-turn indexing.
Typical Applications
- Supports reliable machine operation
- Improves integration consistency across projects
- Contributes to service-friendly panel design
- Helps reduce lifecycle support complexity
- Supports production uptime objectives
- Enables practical modernization paths
Buying Checklist
- Industrial-grade integration reliability
- Supports maintainable automation design
- Improves production stability objectives
- Practical fit for OEM and retrofit use
- Useful for long-term lifecycle planning
Technical Specifications
| Model | E6CP-AG5C 256P-R |
|---|---|
| Series | E6CP |
| Type | Absolute Rotary Encoder |
| Body Diameter | Φ40mm |
| Shaft Diameter | Φ6mm |
| Resolution | 256 P/R (8-bit) |
| Output Code | Gray Code (parallel 8-bit) |
| Supply Voltage | DC5-24V ±10% |
| Current Consumption | 100mA max |
| Max Rotational Speed | 6000rpm |
| Cable Length | 0.5m pre-wired |
| Protection Rating | IP50 |
| Operating Temperature | -10 to +70°C |
| Starting Torque | 0.9mN·m max |
| Moment of Inertia | 1×10⁻⁶ kg·m² |
| Shaft Load (Radial) | 30N max |
| Shaft Load (Axial) | 20N max |
| Position Memory | Retains position when powered off (single-turn) |
