Omron NX-AD3204 Analog Input Unit 4-Channel Universal
Omron NX-AD3204 is a 4-channel universal analog input unit for NX series, accepting voltage and current inputs for process monitoring.
USD 160.00 per unit, volume discounts available
- In stock, ships in 24h
- 100% genuine Omron
- 1-year manufacturer warranty
- Worldwide delivery
Key Features
- Multi-channel analog signal integration for NX platforms
- Supports analog acquisition/conversion in modular architectures
- Suitable for EtherCAT-oriented industrial control systems
- Improves process variable visibility for better control tuning
- Useful in mixed discrete-plus-analog machine applications
- Supports scalable diagnostics and maintainable channel mapping
Multi-Channel Analog Integration for Data-Rich NX Control Systems
The NX-AD3204 supports analog signal handling in modular NX environments where process visibility and precise variable monitoring are required. It is suitable for integrating transmitters and analog devices into EtherCAT-driven machine architectures. This module helps engineers build scalable mixed-signal systems with maintainable diagnostics and clean panel design.
Typical Applications
- Reading pressure and flow transmitter signals
- Monitoring analog process variables in utility skids
- Supporting closed-loop process tuning in machine systems
- Expanding analog capacity in existing NX installations
- Standardizing analog module architecture in OEM platforms
- Modernizing legacy analog interfaces with modular NX design
Buying Checklist
- Multi-channel capability improves analog integration efficiency
- Strong fit for process-variable-driven machine control
- Supports scalable EtherCAT-based architecture growth
- Enhances diagnostics and maintainability for analog signals
- Practical module for mixed-signal automation expansion
Technical Specifications
| Model | NX-AD3204 |
|---|---|
| Series | NX |
| Type | Analog Input Unit |
| Input Channels | 4 channels |
| Input Types | Voltage: 0-10V, ±10V; Current: 0-20mA, 4-20mA |
| Resolution | 1/32000 |
| Accuracy | ±0.1% full scale |
| Conversion Time | 1ms per channel |
| Input Impedance | 1MΩ (voltage), 250Ω (current) |
| Isolation | Channel-to-channel isolated |
| Connection | Push-in terminals |
| Current Consumption | 80mA at 5VDC |
| Operating Temperature | 0 to +55°C |
| Mounting | DIN rail |
Frequently Asked Questions
What sensors can I connect to this analog input?
Voltage output: pressure transmitters (0-10V), temperature transmitters. Current loop: 4-20mA pressure, flow, level transmitters. Universal input suits most industrial sensors.
How do I wire 4-20mA current input?
Connect sensor + to input +, sensor - to input -. Unit provides 250Ω internal shunt. For external shunt or powered sensors, follow wiring diagram.
What's the resolution in engineering units?
For 0-10V: 10V/32000 = 0.31mV per count. For 4-20mA: 16mA/32000 = 0.5μA per count. Scale in controller to engineering units.
Can I use this for thermocouple input?
No, NX-AD3204 is for voltage/current only. For thermocouples, use NX-TC temperature input units with cold junction compensation.
