Omron NX-ECC203 EtherCAT Coupler Unit for NX I/O
Omron NX-ECC203 is an EtherCAT coupler unit connecting NX series I/O to EtherCAT network for distributed I/O systems.
USD 105.00 per unit, volume discounts available
- In stock, ships in 24h
- 100% genuine Omron
- 1-year manufacturer warranty
- Worldwide delivery
Key Features
- EtherCAT connector/coupler role for NX I/O integration
- Supports deterministic communication in distributed systems
- Enables scalable decentralized machine architecture
- Reduces central cabinet wiring complexity
- Suitable for OEM and retrofit expansion projects
- Improves maintainability via segmented I/O topology
High-Speed EtherCAT Connectivity for Scalable NX Distributed Control
The NX-ECC203 provides a structured connection point for distributed NX I/O systems that require fast deterministic communication. It is suitable for machine zones where decentralized architecture improves wiring efficiency and maintenance access. This unit supports scalable expansion in OEM platforms and modernization programs.
Typical Applications
- Connecting distributed NX slices to EtherCAT networks
- Building machine-zone I/O segments on long lines
- Expanding remote I/O in phased upgrade projects
- Reducing wiring runs from main cabinets
- Standardizing EtherCAT coupler usage in OEM designs
- Improving serviceability of large automation systems
Buying Checklist
- Deterministic communication improves control consistency
- Supports modular distributed architecture growth
- Reduces installation complexity in large systems
- Strong fit for modern EtherCAT machine designs
- Practical component for long-term scalable automation
Technical Specifications
| Model | NX-ECC203 |
|---|---|
| Series | NX |
| Type | EtherCAT Coupler Unit |
| Ethernet Ports | 2 ports (100 Mbps) |
| Protocol | EtherCAT |
| Max I/O Points | 512 inputs, 512 outputs |
| Max NX Units | 64 units |
| Cycle Time | 0.5ms minimum |
| Supply Voltage | 24VDC (20.4-28.8V) |
| Current Consumption | 150mA at 24VDC |
| Connection | Push-in terminals |
| Mounting | DIN rail |
| Operating Temperature | 0 to +55°C |
| Certifications | CE, UL, CSA, EtherCAT |
Frequently Asked Questions
What controllers work with NX-ECC203?
NJ/NX series machine controllers (EtherCAT master), third-party EtherCAT masters (Beckhoff, TwinCAT, etc.). Any EtherCAT master can control NX I/O via ECC203.
How many NX I/O units can I connect?
Maximum 64 NX units per coupler. Limited by power budget and I/O capacity. For more I/O, add additional couplers on same EtherCAT network.
What's the advantage of EtherCAT?
High speed (0.5ms cycle), long distance (100m between nodes), simple topology (daisy-chain), multi-vendor compatibility. Ideal for distributed I/O systems.
Do I need to configure each I/O unit?
No, NX-ECC203 auto-recognizes connected NX units. Configuration done in Sysmac Studio: add coupler to network, I/O allocation automatic.
