SKU: NX-ID5342
Omron NX-ID5342 Digital Input Unit 8-Point 24VDC NPN
Omron NX-ID5342 is an 8-point 24VDC NPN digital input unit for NX series EtherCAT I/O systems with high-speed response.
USD 41.00 per unit, volume discounts available
- In stock, ships in 24h
- 100% genuine Omron
- 1-year manufacturer warranty
- Worldwide delivery
Key Features
- 8-point digital input capacity for compact I/O sections
- NPN 24VDC input compatibility for industrial sensors
- Designed for NX/EtherCAT modular architectures
- Suitable for interlock and sensor signal collection
- Supports clear channel-level diagnostics and maintenance
- Useful for incremental expansion in existing NX systems
Compact 8-Point Digital Input Expansion for Distributed NX Control
The NX-ID5342 supports acquisition of discrete machine signals in compact sections where modest channel count and reliable diagnostics are priorities. Its 24VDC NPN compatibility suits common industrial sensing patterns. This module is practical for OEM machine designs and retrofit expansions that require maintainable, scalable modular I/O structure.
Typical Applications
- Collecting local sensor states in machine zones
- Monitoring interlock signals in compact stations
- Expanding input capacity in NX control racks
- Supporting distributed I/O layouts in OEM systems
- Replacing older input slices in retrofit projects
- Standardizing low-count input blocks for modular designs
Buying Checklist
- Compact 8-point format reduces hardware overhead
- NPN/DC compatibility suits common field sensor setups
- Scales cleanly in modular NX architecture growth
- Improves maintainability via channelized diagnostics
- Practical option for targeted I/O expansion
Technical Specifications
| Model | NX-ID5342 |
|---|---|
| Series | NX |
| Type | Digital Input Unit |
| Input Points | 8 points |
| Input Voltage | 24VDC |
| Input Type | NPN (sinking) |
| Response Time | 0.1ms standard |
| Connection | Push-in terminals |
| Current Consumption | 30mA at 5VDC |
| Mounting | DIN rail |
| Operating Temperature | 0 to +55°C |
Frequently Asked Questions
What's the difference between NX-ID5142-5 and NX-ID5342?
NX-ID5142-5: 16 points. NX-ID5342: 8 points. Same electrical specifications. Choose based on I/O density requirements. 8-point unit useful when you need fewer inputs.
Can I mix NX and CJ I/O in same system?
No, NX I/O connects via EtherCAT to NJ/NX controllers. CJ I/O connects via backplane to CJ CPUs. For mixed systems, use NJ controller with CJ interface unit or separate PLCs.
What wire size fits push-in terminals?
22-16 AWG (0.5-1.5mm²) solid or stranded wire. Use ferrules for stranded wire. Insert straight, push firmly until wire seats.
How do I remove wire from push-in terminal?
Insert small screwdriver into release slot next to terminal, press while pulling wire. Don't pull wire without releasing spring.
