Omron NX-PG0112 NX Series Pulse Output Unit 2-Axis Position Control

Omron NX-PG0112 Position Control Unit

The Omron NX-PG0112 is a 2-axis pulse output unit designed for the NX series of modular PLCs. This position control unit generates pulse trains for controlling servo drives and stepper motors, enabling precise positioning control for industrial automation applications. The NX-PG0112 supports various pulse output formats including CW/CCW pulse, pulse/direction, and quadrature, providing compatibility with most servo and stepper drive systems. Each axis supports independent positioning control with linear interpolation capability, allowing coordinated motion control for two axes. The unit features high-speed pulse output up to 1 MHz, suitable for high-speed positioning applications. The NX-PG0112 connects to the NX bus and is configured using the Sysmac Studio software, which provides intuitive axis parameter setup and programming. With its compact DIN rail mounting design, the NX-PG0112 integrates easily into NX automation systems for applications including packaging machinery, assembly equipment, and general positioning control.
