Omron P2RFZ-08-E Push-in Terminal Socket 8-Pin
Omron P2RFZ-08-E is an 8-pin relay socket with push-in terminals for tool-less wiring of G2R/H5CZ series relays.
USD 1.50 per unit, volume discounts available
- In stock, ships in 24h
- 100% genuine Omron
- 1-year manufacturer warranty
- Worldwide delivery
Key Features
- Push-in terminal for fast wiring
- 8-pin configuration for H5CZ
- DIN rail mounting
- Accommodates solid/stranded wires
- Tool-free connection
- Compact design
- IP20 protection rating
Omron P2RFZ-08-E Timer Relay Socket
The Omron P2RFZ-08-E is an 8-pin push-in terminal socket designed specifically for H5CZ series timer relays from Omron. This socket provides a convenient and reliable method for connecting timer relays in industrial control panels. The push-in terminal technology enables fast and tool-free wiring, significantly reducing installation time compared to traditional screw-terminal sockets. The P2RFZ-08-E supports both solid and stranded conductors within the 0. 5-2. 5 mm² range, providing flexibility for various wiring scenarios. The socket features DIN rail mounting capability, allowing for quick installation and easy removal for maintenance or replacement. The compact design and clear terminal markings help save panel space and reduce wiring errors during installation. This socket is ideal for control panel builders and automation integrators working with Omron H5CZ timer relays in applications such as industrial timing, sequencing, and delay functions.
Typical Applications
- Industrial timer circuits
- Conveyor delay controls
- Machine timing functions
- Sequencing equipment
- Lighting control timing
- Motor control delays
- Process automation timing
- Panel building
Buying Checklist
- Fast push-in wiring reduces labor
- Reliable spring contact connection
- Easy DIN rail installation
- Compact size saves panel space
- Compatible with popular H5CZ timers
- Clear markings prevent errors
- Professional appearance
Technical Specifications
| Model | P2RFZ-08-E |
|---|---|
| Series | P2RFZ |
| Pin Count | 8-pin |
| Connection Type | Push-in spring terminals |
| Compatible Relays | G2R-2, H5CZ series |
| Terminal Capacity | 22-16 AWG (0.5-1.5mm²) |
| Mounting | Panel or DIN rail |
| Rated Current | 10A |
| Rated Voltage | 250VAC |
| Operating Temperature | -25 to +55°C |
Frequently Asked Questions
What relays fit 8-pin push-in socket?
G2R-2 series relays, H5CZ series counters, and standard 8-pin tube base relays. Check relay base matches socket pin configuration.
Is push-in as reliable as screw terminals?
Yes, push-in spring terminals are UL/CSA certified and meet same standards as screw terminals. Spring force maintains constant contact pressure, resistant to vibration loosening.
Can I DIN rail mount this socket?
Yes, includes DIN rail clip. Also supports panel mounting. DIN rail mounting allows easy socket replacement without rewiring.
What's the wire stripping length?
10mm (3/8 inch) stripping length for push-in terminals. Too short: won't make contact. Too long: exposed conductor outside terminal.
