Omron PYFZ-14-E Relay Socket Terminal Base
Omron PYFZ-14-E is a 14-pin relay socket terminal base for LY series and other 14-pin relays.
USD 0.95 per unit, volume discounts available
- In stock, ships in 24h
- 100% genuine Omron
- 1-year manufacturer warranty
- Worldwide delivery
Key Features
- Relay socket terminal base accessory
- Supports compatible plug-in relay installation
- Enables quick relay replacement without rewiring
- Improves control panel wiring structure and clarity
- Suitable for OEM and retrofit control cabinets
- Supports maintainable lifecycle service practices
Relay Socket Base for Structured Panel Wiring and Serviceability
PYFZ-14-E belongs to Omron relay socket accessory lineup and is used to mount compatible plug-in relays while maintaining fixed terminal wiring in the cabinet. Socket-based designs are widely used in industrial control panels because they simplify relay replacement and reduce downtime during maintenance. This model is commonly selected in OEM builds, retrofit projects, and utility panels requiring clear wiring organization and repeatable service workflow. Engineering teams should validate relay compatibility, terminal current rating, wire gauge support, and mounting method. During commissioning and maintenance, terminal torque discipline, labeling quality, and periodic inspection are essential for long-term reliability. PYFZ-14-E is typically chosen when maintainable relay architecture is a core panel design objective.
Typical Applications
- Plug-in relay mounting in machine panels
- Interposing relay circuits for PLC output isolation
- Serviceable relay architecture in utility cabinets
- Retrofit replacement of damaged relay bases
- Standardized panel assembly across machine variants
- Diagnostic relay sections with organized terminal wiring
Buying Checklist
- Confirm exact relay/socket compatibility before ordering.
- Validate terminal load and wiring gauge requirements.
- Check mounting layout and service access in cabinet design.
- Use ferrules and torque standards for reliable connections.
- Keep spare sockets for fast maintenance replacement.
Technical Specifications
| Model | PYFZ-14-E |
|---|---|
| Series | PYFZ |
| Pin Count | 14-pin |
| Connection Type | Screw terminals |
| Compatible Relays | LY2, MY2 series |
| Terminal Capacity | 22-14 AWG |
| Mounting | Panel or DIN rail |
| Rated Current | 10A |
| Rated Voltage | 250VAC |
Frequently Asked Questions
What relays fit 14-pin socket?
LY2 series, MY2 series, and other 14-pin tube base relays. Common for DPDT relays with LED indicator.
What's the difference between 8-pin and 14-pin?
8-pin: SPDT or DPDT relays. 14-pin: DPDT relays with LED, or 4PDT relays. More pins = more contact circuits or additional features.
Can I DIN rail mount this socket?
Yes, includes DIN rail mounting clip. Also supports panel mounting with screws.
What wire size fits terminals?
22-14 AWG (0.5-2.5mm²) solid or stranded wire. Use ferrules for stranded wire. Torque: 0.5-0.6 N·m.
