SKU: R88D-KT02H-Z
Omron R88D-KT02H-Z Accurax G5 Servo Drive, 200 W, 200 VAC, Analog/Pulse, with Safety
Omron R88D-KT02H-Z Accurax G5 servo drive, 200 W, single-phase 200 VAC, analog ±10 V or pulse-train command input, with STO/SS1/SLS safety (-Z), for pulse-command PLC retrofits.
USD 360.00 per unit, volume discounts available
- In stock, ships in 24h
- 100% genuine Omron
- 1-year manufacturer warranty
- Worldwide delivery
Key Features
- 200 W continuous output at 3000 rpm motor class
- Single-phase 200–230 VAC input
- Analog ±10 V or pulse-train (line-driver / open-collector) command input
- Integrated safety: STO, SS1, SLS per IEC 61800-5-2 (discrete 24 VDC safety inputs)
- 20-bit absolute encoder feedback with the matching R88M-K motor
- One-button auto-gain tuning with manual override
- Built-in regenerative resistor
- DIN-rail or panel mount
200 W G5 analog/pulse servo drive with safety option
The Omron R88D-KT02H-Z is a 200 W, single-phase 200 VAC G5 servo drive with the analog/pulse-train command interface and the safety option. The "KT" prefix in the R88D ordering code denotes the analog/pulse-train command family — used in applications where the controller issues a ±10 V analog velocity/torque command or a step/direction pulse train rather than a fieldbus command.
This drive family is the right choice for retrofitting an existing line where the controller is a pulse-output PLC (CP1H-Y, CP1L, or a non-Omron PLC) rather than a Sysmac NJ/NX. Pulse-train position control gives reliable point-to-point motion using the PLC's high-speed pulse output, with no need to add an EtherCAT master.
The "-Z" suffix adds the safety option: STO (Safe Torque Off), SS1 (Safe Stop 1) and SLS (Safely Limited Speed) per IEC 61800-5-2, activated by discrete safety inputs (24 VDC) on the drive's safety connector. Note that on the KT-family (analog/pulse) drives, the safety I/O is hard-wired, not FSoE — that is because the analog/pulse command interface is not EtherCAT.
Matching motor: R88M-K20030H (no brake) or R88M-K20030H-B (with brake) in the 200 V 3000 rpm family. The drive carries a built-in regenerative resistor for typical 200 W duty.
Typical Applications
- Retrofit of pulse-output PLC systems to current G5 hardware
- Stepper-replacement upgrades where 200 W servo performance is needed
- Stand-alone positioning axes on packaging / cutting machines
- Safety-rated axes with discrete safety wiring (no safety bus)
- Replacement for legacy Omron SMX/SMY servo systems
Buying Checklist
- If you need fieldbus, use the EtherCAT (-ECT) variant — this drive is analog/pulse only
- For 24 VDC discrete safety wiring, the -Z variant's safety connector is the standard interface
- For pulse input, decide between line-driver and open-collector — they are different pulse-input pins
- Match the motor to the 200 V 200 W class
- For pulse frequencies above 200 kpps, use the line-driver pulse input (not the open-collector)
Technical Specifications
| Series | Accurax G5 (R88D-KT) |
|---|---|
| Model | R88D-KT02H-Z |
| Drive type | Analog/pulse-train servo drive with safety |
| Continuous output | 200 W |
| Applicable motor | R88M-K20030H / R88M-K20030H-B (200 VAC, 3000 rpm) |
| Input voltage | Single-phase 200–230 VAC, 50/60 Hz |
| Control method | PWM sine-wave, IGBT |
| Command input | Analog ±10 V (velocity/torque) OR pulse train (step + direction / A + B) |
| Pulse input modes | Line-driver (RS-422) or open-collector, up to 500 kpps line-driver |
| Encoder feedback | 20-bit absolute serial encoder |
| Safety functions | STO, SS1, SLS per IEC 61800-5-2 (hard-wired 24 VDC inputs) |
| Safety rating | SIL 3 / PL e (with suitable safety circuit) |
| Control modes | Position (pulse-train), velocity (analog), torque (analog) |
| Gain tuning | Auto (one-button) and manual |
| Protective functions | Overcurrent, overload, overvoltage, undervoltage, overspeed, encoder error, regenerative discharge |
| Operating temperature | 0 °C to +55 °C |
| Storage temperature | -20 °C to +65 °C |
| Mounting | DIN rail or panel mount |
Frequently Asked Questions
Can I use this drive with an NJ or NX controller?
Technically yes — you wire the NJ/NX high-speed output to the drive's pulse input. But this loses most of the value of an NJ/NX system. For new NJ/NX designs, use the EtherCAT (-ECT) variant instead.
How are the safety functions wired?
On the KT-family drives, safety is hard-wired: 24 VDC discrete inputs on the drive's safety connector. The EtherCAT FSoE safety protocol is only available on the EtherCAT -Z variants. Both deliver the same STO / SS1 / SLS behaviour; the difference is the wiring.
What's the maximum pulse frequency?
500 kpps on the line-driver input, 200 kpps on the open-collector input. For most pulse-output PLCs the line-driver input is the right choice.
