SKU: Z-15GW4-B
Omron Z-15GW4-B Limit Switch SPDT 15A Pin Plunger
Omron Z-15GW4-B is a SPDT limit switch with pin plunger actuator, 15A rating for direct mechanical position sensing applications.
USD 4.50 per unit, volume discounts available
- In stock, ships in 24h
- 100% genuine Omron
- 1-year manufacturer warranty
- Worldwide delivery
Key Features
- Contact Form: SPDT (1 Form C)
- Contact Rating: 15A at 250VAC
- Actuator Type: Pin plunger
- Operating Force: 2.94N max
- Pre-Travel: 0.5-1.5mm
- Over-Travel: 1.5mm min
Reliable Detection Layer for Sequence Accuracy and Process Stability
The Z-15GW4-B is used to deliver repeatable machine-state detection for sequencing, interlocks, and process confirmation. Whether in packaging, handling, or assembly systems, this sensing class helps reduce false triggers and improves control confidence under continuous operation.
Repeatable State Detection
Accurate detection at the right process moment improves sequence integrity and reduces quality escapes caused by timing uncertainty or missed events.
Fit for Demanding Machine Environments
Industrial sensing components are selected for stability under vibration, contamination, and repetitive duty where consumer-grade devices are not suitable.
Faster Commissioning and Replacement
Standardized sensor families simplify spare strategy, reduce replacement errors, and support quicker return to production after maintenance events.
Typical Applications
- Provides stable detection signals to PLC logic
- Improves sequence timing accuracy
- Reduces dependence on mechanical contact methods
- Supports high-cycle production operation
- Enables better fault isolation at machine stations
- Simplifies maintenance through standard sensor families
Buying Checklist
- Repeatable industrial detection behavior
- Designed for continuous machine duty
- Improves process timing confidence
- Serviceable and standardizable selection
- Reliable fit for automation sensing layers
Technical Specifications
| Model | Z-15GW4-B |
|---|---|
| Series | Z |
| Type | Limit Switch |
| Contact Form | SPDT (1 Form C) |
| Contact Rating | 15A at 250VAC |
| Actuator Type | Pin plunger |
| Operating Force | 2.94N max |
| Pre-Travel | 0.5-1.5mm |
| Over-Travel | 1.5mm min |
| Mechanical Life | 10 million operations |
| Electrical Life | 50,000 operations |
| Operating Temperature | -25 to +80°C |
| Protection | IP00 |
| Terminal Type | Screw terminals |
Frequently Asked Questions
When should I use pin plunger vs roller lever?
Pin plunger for: direct pressing applications, limited space where lever won't fit, linear motion detection. Roller lever for: cam operation, rotating mechanisms, reduced friction requirements, continuous cycling.
What's the operating force for pin plunger?
2.94N (300gf) maximum operating force. Ensure your mechanism can provide this force with some margin. For lower force requirements, consider high-sensitivity basic switches.
Can I mount this switch in any orientation?
Yes, pin plunger works in any orientation. For vertical mounting with plunger facing down, ensure mechanism provides positive actuation. For plunger facing up, consider dust cover to prevent contamination.
What's the typical application for pin plunger limit switch?
End-of-travel detection, part presence sensing, door/window position, safety interlock (non-safety rated), manual override detection, and any application requiring direct linear actuation.
