Omron NX-ID5142-5 Digital Input Unit 16-Point 24VDC NPN
Omron NX-ID5142-5 is a 16-point 24VDC NPN digital input unit for NX series EtherCAT I/O systems, providing reliable signal acquisition.
USD 62.00 per unit, volume discounts available
- In stock, ships in 24h
- 100% genuine Omron
- 1-year manufacturer warranty
- Worldwide delivery
Key Features
- 16 digital input points in NX modular slice format
- 24VDC signal class for common industrial sensor wiring
- Sysmac-compatible integration for unified engineering workflow
- Supports scalable machine I/O architecture planning
- Useful in both new machine builds and retrofit expansions
- Channel-oriented diagnostics assist faster troubleshooting
Modular 24VDC Input Expansion for Scalable NX Automation
The NX-ID5142-5 is designed for stable acquisition of field sensor and switch signals in distributed NX control systems. Its 16-channel format supports practical panel density while keeping commissioning and maintenance manageable. The module is suited for machine builders seeking consistent I/O standards across equipment families, especially where future expansion and long-term service continuity are priorities.
Typical Applications
- Reading proximity and photoelectric sensors
- Monitoring machine interlocks and guard switches
- Collecting fixture feedback in assembly stations
- Expanding input capacity in existing NX racks
- Standardizing input layout across OEM machine models
- Capturing status signals in conveyor transfer zones
Buying Checklist
- Reliable 24VDC signal handling for industrial environments
- Modular format supports low-risk future expansion
- Improves consistency in PLC input mapping and service
- Space-efficient option for dense control cabinets
- Good fit for long-term standardized platform design
Technical Specifications
| Model | NX-ID5142-5 |
|---|---|
| Series | NX |
| Type | Digital Input Unit |
| Input Points | 16 points |
| Input Voltage | 24VDC (20.4-28.8V) |
| Input Type | NPN (sinking) |
| Input Current | 7mA typical at 24VDC |
| ON Voltage | 14.4V minimum |
| OFF Voltage | 5V maximum |
| Response Time | 0.1ms (standard), 0.01ms (high-speed) |
| Common | 16 points/common, 1 circuit |
| Connection | Push-in terminals |
| Current Consumption | 30mA at 5VDC (internal) |
| Mounting | DIN rail or panel |
| Operating Temperature | 0 to +55°C |
| Certifications | CE, UL, CSA |
Frequently Asked Questions
What controllers is this input unit compatible with?
NX-ID5142-5 works with NJ/NX series machine controllers and NX-ECC EtherCAT couplers. Connects via EtherCAT network. Not compatible with CJ/CP series without EtherCAT master.
Can I use this input with 24VDC sensors?
Yes, 24VDC input range accepts standard proximity sensors, photoelectric sensors, and limit switches. Connect sensor + to external 24V+, sensor output to input terminal, input COM to 24V-.
What's the advantage of push-in terminals?
Tool-less wiring: insert stripped wire, pushes in automatically. 50% faster wiring vs screw terminals. Vibration-resistant spring grip. No torque wrench needed. Ideal for high-volume panel building.
Can I use this for high-speed counting?
Standard mode: 0.1ms response (5kHz). High-speed mode: 0.01ms response (50kHz). For higher frequency counting (100kHz+), use NX series high-speed counter unit.
How do I configure this unit?
Configure in Sysmac Studio: add unit to EtherCAT network, set I/O allocation, configure filter settings. Configuration downloads to controller. Unit auto-recognizes on network.
