SKU: NX-OD5121-1
Omron NX-OD5121-1 Digital Output Module 16-Channel NPN Transistor
Omron NX-OD5121-1 is a 16-channel NPN transistor output module for NX series EtherCAT I/O systems.
USD 62.00 per unit, volume discounts available
- In stock, ships in 24h
- 100% genuine Omron
- 1-year manufacturer warranty
- Worldwide delivery
Key Features
- 16-channel digital output capacity in compact NX format
- NPN transistor outputs for responsive switching behavior
- Designed for scalable modular control architecture
- Suitable for high-cycle actuator command tasks
- Supports maintainable channel-level diagnostics
- Practical for both new builds and retrofit expansion
16-Channel NPN Output Expansion for Scalable NX Machine Control
The NX-OD5121-1 provides discrete output channels for driving actuators, relays, and interface circuits in modular NX control systems. NPN transistor outputs support fast switching behavior in high-cycle applications. This module is suitable for OEM machine designs and retrofit expansions requiring dependable, maintainable output architecture.
Typical Applications
- Driving actuator outputs in machine stations
- Switching relay interfaces for auxiliary controls
- Expanding output capacity in NX control racks
- Standardizing NPN output sections in OEM platforms
- Retrofitting legacy output layers with modular architecture
- Improving command channel reliability in repetitive automation
Buying Checklist
- 16 channels provide practical output density
- NPN transistor outputs suit high-cycle switching tasks
- Scales cleanly in modular NX control architectures
- Supports maintainable service workflows and expansion
- Strong fit for modern machine output design strategies
Technical Specifications
| Model | NX-OD5121-1 |
|---|---|
| Series | NX |
| Type | Digital Output Unit |
| Output Points | 16 points |
| Output Type | NPN (sinking) |
| Load Voltage | 24VDC |
| Output Current | 0.5A per point |
| Response Time | 0.1ms ON, 0.5ms OFF |
| Connection | Push-in terminals |
| Current Consumption | 40mA at 5VDC |
| Mounting | DIN rail |
| Operating Temperature | 0 to +55°C |
Frequently Asked Questions
What's the difference between NX-OD5121-1 and NX-OD5121-5?
NX-OD5121-1: 16 points. NX-OD5121-5: 32 points. Same electrical specs. Choose based on I/O density needs.
Can I parallel outputs for higher current?
Yes, parallel multiple outputs from same common for up to 2A combined. Ensure all outputs switch simultaneously.
Do I need external fuse?
Unit has internal short-circuit protection, but external fusing recommended for load protection. Use 0.5-1A fast-blow fuse per output.
Is this output suitable for stepper motor control?
No, OD5121 is for on/off switching. For stepper motor pulse/direction, use NX-PG pulse output unit or controller built-in pulse outputs.
