Omron NX-OD5121-5 Digital Output Unit 32-Point NPN Transistor
Omron NX-OD5121-5 is a 32-point NPN transistor output unit for NX series EtherCAT I/O systems, providing high-density DC output.
USD 72.00 per unit, volume discounts available
- In stock, ships in 24h
- 100% genuine Omron
- 1-year manufacturer warranty
- Worldwide delivery
Key Features
- Output Points: 32 points
- Output Type: NPN (sinking)
- Load Voltage: 24VDC (20.4-28.8V)
- Output Current: 0.5A per point, 4A per unit
- Leakage Current: 0.1mA max
- Response Time: 0.1ms ON, 0.5ms OFF
Scalable PLC Control Foundation for OEM and Retrofit Projects
The NX-OD5121-5 fits industrial control projects that require dependable logic execution, maintainable programming workflows, and architecture growth over the equipment lifecycle. It supports standardized automation design across machine families while preserving serviceability in production environments.
Deterministic Logic and Sequence Control
This controller class supports predictable scan-driven execution for interlocks, sequencing, alarms, and coordinated device handling. Deterministic behavior is essential for consistent machine output and repeatable cycle performance.
Platform Reuse Across Equipment Variants
Standardizing on a proven PLC/controller family enables software reuse, reduced engineering lead time, and easier support across multiple machine models or production lines.
Lifecycle Service and Maintainability
A maintainable control architecture with documented I/O mapping, diagnostics, and modular expansion strategy reduces troubleshooting time and improves long-term ownership value.
Typical Applications
- Executes deterministic control logic
- Coordinates multi-device machine behavior
- Supports reusable software structures
- Improves fault diagnostics and recovery time
- Enables modular feature growth over time
- Standardizes control strategy across equipment
Buying Checklist
- Strong fit for scalable machine control
- Maintains deterministic automation behavior
- Supports long-term maintainability
- Good platform standardization candidate
- Reliable industrial controller ecosystem
Technical Specifications
| Model | NX-OD5121-5 |
|---|---|
| Series | NX |
| Type | Digital Output Unit |
| Output Points | 32 points |
| Output Type | NPN (sinking) |
| Load Voltage | 24VDC (20.4-28.8V) |
| Output Current | 0.5A per point, 4A per unit |
| Leakage Current | 0.1mA max |
| Response Time | 0.1ms ON, 0.5ms OFF |
| Common | 16 points/common, 2 circuits |
| Protection | Short-circuit, overload |
| Connection | Push-in terminals |
| Current Consumption | 50mA at 5VDC |
| Mounting | DIN rail |
| Operating Temperature | 0 to +55°C |
Frequently Asked Questions
What loads can this output unit switch?
0.5A per point: solenoid valves, indicator lamps, small relays, pilot lights. For higher current loads, use output to control external relay/contactor.
What's the maximum total current?
4A per unit maximum. With 32 outputs, if all ON, each limited to 0.125A average. Plan load distribution to stay within unit rating.
What happens during short circuit?
Internal protection shuts off output. Fault indicated in controller. Output resets when short removed and controller cycles. Repeated shorts may damage unit.
Can I use this output for PWM control?
Yes, transistor output supports PWM. Max frequency: approximately 5kHz. For high-frequency PWM, use dedicated high-speed output unit.
