SKU: NX-AD2203
Omron NX-AD2203 Analog Input Unit 3 Channels
Omron NX-AD2203 is a 3-channel analog input unit for NX series, accepting voltage and current inputs for process monitoring.
USD 120.00 per unit, volume discounts available
- In stock, ships in 24h
- 100% genuine Omron
- 1-year manufacturer warranty
- Worldwide delivery
Key Features
- 3 channels of analog input
- 16-bit resolution for precise measurement
- Voltage and current input support
- Isolated inputs for noise immunity
- Fast EtherCAT connectivity
- LED status indicators
- Hot swapping support
- Compact DIN rail mount
High-Precision Analog Input for Process Monitoring
The Omron NX-AD2203 is an analog input unit from the NX Series I/O system, designed to interface analog sensors and transducers with NX Series controllers. This module provides 3 channels of analog input with 16-bit resolution, supporting both voltage and current input signals. The NX-AD2203 is ideal for monitoring process variables such as temperature, pressure, flow, and level in industrial applications. Its high resolution ensures accurate measurement, while the isolated inputs provide protection against electrical noise and ground loops. The module connects to the NX controller via EtherCAT, enabling fast data transfer and simple configuration through Sysmac Studio.
Typical Applications
- Temperature monitoring with analog sensors
- Pressure transducer interfacing
- Flow meter signal acquisition
- Level measurement systems
- Process automation and control
- Quality control monitoring
Buying Checklist
- Confirm sensor output type matches module input range
- Verify resolution meets application accuracy requirements
- Check EtherCAT network configuration capacity
- Consider isolated inputs for noisy environments
Technical Specifications
| Model | NX-AD2203 |
|---|---|
| Series | NX |
| Type | Analog Input Unit |
| Input Channels | 3 channels |
| Input Types | Voltage: 0-10V; Current: 0-20mA, 4-20mA |
| Resolution | 1/32000 |
| Accuracy | ±0.1% full scale |
| Conversion Time | 1ms per channel |
| Input Impedance | 1MΩ (voltage), 250Ω (current) |
| Isolation | Channel-to-channel isolated |
| Connection | Push-in terminals |
| Current Consumption | 50mA at 5VDC |
| Operating Temperature | 0 to +55°C |
Frequently Asked Questions
What sensors can I connect to this analog input?
Voltage output: pressure transmitters (0-10V), temperature transmitters. Current loop: 4-20mA pressure, flow, level transmitters.
Can I configure each channel independently?
Yes, each channel independently configurable for voltage or current. Set in Sysmac Studio.
What's the resolution in engineering units?
For 0-10V: 10V/32000 = 0.31mV per count. For 4-20mA: 16mA/32000 = 0.5μA per count.
Do I need external power for 4-20mA sensors?
No, unit provides 24VDC supply for 2-wire transmitters. Connect sensor + to unit's 24V+, sensor - to input +.
